Suspension Agent | Organo clay For Hydraulic fracturing

Suspension Agent | Organo clay For Hydraulic fracturing
Suspension Agent is an important additive in the hydraulic fracturing fluid. The suspension agent we provide can improve the suspension performance very well whether it is in oilfield drilling or fracturing drilling fluid.

mailEmail: [email protected]

Product details

Suspension Agent | Organo clay For Hydraulic fracturing

Suspension Agent is an important additive in the hydraulic fracturing fluid. The suspension agent we provide can improve the suspension performance very well whether it is in oilfield drilling or fracturing drilling fluid.

Index /Suspension Agent Test Result
10min 1h 12h 24h
θ600 32 33 37 36
θ300 20 20 21 21
θ200 12 11 15 16
θ100 11 11 11 12
θ6 10 10 10 9
θ3 10 9 10 9
AV (CP) 16 16.5 18.5 18
PV (CP) 12 13 16 15
YP (lb/100 ft2) 8 7 5 6
ES (V) 2030 2048 2048 2048

Properties

Composition                      Organically modified bentonite clay

Appearance                       Off white to tan finely divided powder,

Moisture content (105℃,2hr)         ≤3.5%

Particle size (<76μm or 200mesh)    ≥98%

Specific Gravity                    1.7

Advantages

  • Disperses easily in less time with less shear
  • High performance viscosifier for low aromatic, all mineral oil and synthetic base fluids
  • Cost- effectively builds viscosity and yield point
  • Aids control of fluid loss to the formation
  • Increases emulsion stability
  • Suspends weighting  materials and other solids
  • Confers stability at the pressure and temperature 108Pa and 230℃

Application

Base oil:

  • Diesel Oils
  • Crude Oils
  • Mineral Oils
  • Synthetic Oil
  • Alpha Olefins
  • Low BTEX base oil

Viscosifying drilling Fluids:

  • Oil based drilling fluids
  • Invert emulsion fluids
  • Workover fluidsl
  • Completion fluids
  • Casing packs
  • Packer fluids
  • Spotting fluids

Safety

All safety information is provided in the Material Safety Data Sheets for Zhejiang Camp-Shinning New Material Co., Ltd.

Package

Kraft paper bag with PE liner or multi-wall paper sacks or customized. 25kg/bag or 22.68kg/bag or customized

Storage

Suspension Agent CP-992 Store in a dry, well-ventilated area with temperature of 0℃-30℃.  Keep container closed. The quality guarantee period is 24 months.
