Organophilic Clay | How Do You Mix Bentonite For Drilling?
How Do You Mix Organophilic Clay Bentonite For DrillingMore info
Invertent results from organophilic clay bentonite drilling are sometimes neglected. However, in this post, we'll look at how to determine the volume of drilling fluid as well as how to evaluate pH and shear speed.
Continue reading if you want to know how to combine bentonite for drilling.
What is Bentonite Used for In Drilling
What is Bentonite Used for In Drilling?More info
What is the purpose of bentonite in drilling? The answer will vary depending on your location and the type of drilling you do, but it is used for a variety of purposes, including borehole stabilization, soil cutting removal, and increasing the viscosity of drilling mud
Organoclay Bentonite is a organophilic clay.organoclay is a kind of organo clay rheological additive. It is used in systems of non-polar to medium polarity aliphatic and other solvents (ketones, ester, ether esters, alcohols, aromatic).
- High efficiency
- The gel is of light colour and high clarity
- Easy to use, no need to pregel
- Eliminate polar activator
- Consistent development of rheology
- Can be used to post correct
organoclay bentonite is used in the following applications:
- Sealants &adhesives
Composition Organic derivative of a montmorillonite clay
Appearance Fine powder,white
Moisture content (105℃,2hr) ≤3.5%
Loss on ignition (1000℃) 30%-34%
Bulk density 0.35~0.45g/cm3
Fineness (<74μm, %) ≥98%
Dispersion fineness (μm) ≤40
Organoclay can be added directly in powder without polar activator and making pre-gel. But better performance may achieve if polar activator is added and pre-gel procedure is affected.
The addition is recommended to be before grinding procedure to get the best effectiveness. Addition level is commonly 0.2%~1.0%.
What Is Organo Bentonite?
Organo bentonite is a kind of additive with good suspension performance. It can produce a certain viscosity and effectively control the viscosity. In oil-based mud, organo bentonite clay can be used not only in mineral oil, but also in diesel oil and synthetic oil. The organobentonites produced by Camp Shinning can maintain good stability under high temperature and high pressure. Generally, the temperature can be 350 degrees Fahrenheit in summer, and still maintain good stability.
Of course, the organo bentonite clay produced by Camp Shinning can also be widely used in paint production, coating production, ink production, grease production and other fields, playing a better role in anti sagging, thixotropy and anti settlement, etc
What is the application function of organo bentonite?
Organo bentonite can be widely used in oil-based mud.
Effectively improve hole cleanliness during drilling and workover operations.
Keep the suspension function for a long time in packing fluids and casing packs
What are the Advantages of Organo Bentonites?
- First of all, keep the stability under the premise of high temperature. Generally, from 160 ℃ to 220 ℃, Camp Shinning’s organo bentonite can achieve better stability.
- Aids in filtration control
What are the Typical Characteristics of Organo Bentonite ?
The most typical feature of the organo bentonite produced by Camp Shinning is that it looks like white powder. Well, its specific gravity is about 1.7.
What is the Packing Method of Organo Bentonite?
The organic bentonite is packed in paper bags, the inner lining is PE film, can play a moisture-proof role, generally stored in a dry environment, such a bag is enough,usually organo bentonite is packed in 22.68 kg, each bag is equal to 50 pounds, there are also 25 kg, also accept customer requirements of customized..
Recommended use of organobentonites.
Slowly add 2-15 pounds of organo bentonite through the hopper.We recommend adding a small amount of water to reduce the yield time. At the same time, adding a certain amount of water can also play an effective role in dispersion.
Firstly, recommended Level of Camp Shinning organo bentonite are typically 0.2% to 2.0% of the weight of the system.
When organo bentonite is used in formulation, polar activator is needed. Polar activator is acetone/water(95/5). The dosage of activator is 20%-30% of the weight of Camp Shinning organoclay. And also high shear can promote the dispersing of organo bentonite.
Adding procedure as follows:
If condition permits, heat the base oil to 60~70℃
Add organo bentonite while stirring, addition level is 7%-10% of the total formulation. Stir 5~10minutes
Add polar activator, addition level is 2%-3% of the total formulation. Then add other additives, stir 25~30minutes.
Use pump to help it pass colloid grinding and homogenizer. Deair, filtrate, pack.
Note: With High-speed dispersant of grinding machine, and properly prolong the dispersing time, better gelatin performance can be reached.
The formulation which uses organo bentonite as thickener will own high dropping point, thus can be used under high temperature and presents good impermeability and water resistance.
How to choose the organo bentonites for different application fields ?
First of all, we need you to tell us what is your application? Is it paint,coatings,inks ,grease or oil drilling mud?
Secondly, you can also tell us which grade of organic bentonite clay do you used, and we will recommend similar organo bentonites grades to you according to the grade and specification you told us.
Furthermore, you can also tell us your formula and your test procedure.Our engineers will recommend an organo bentonite suitable for your overall needs in our laboratory according to your formula.
What are the types of organobentonites?
The organo bentonites produced by Camp Shinning are divided into solvent based organo bentonite and water based organo bentonite. Generally, water based organo clay is mainly used in the production of paint, paint and ink of inorganic system. The solvent based system of organo bentonite clay is also widely used in the production of paint, paint and grease of solvent-based system.
If we classify them from other dimensions, the organo bentonite produced by the Camp Shinning can also be divided into pre gel type organo bentonite and dispersible organo bentonite clay.
What is the main role of water based organo bentonite in water-based systems?
- High gelling effectiveness, water based organic bentonite clay can form gel even at 2% in water
- Easy dispersing.
- Gel is transparency and of light color
- Prevents pigment Settling
- High thixotropy, Good anti-sag property
What are the advantages of organo bentonite produced by Camp Shinning in oilfield drilling and fracturing fluid?
The main advantages of organobentonites in fracture fluid and oilfield drilling are as follows.
- Effectively suspends weighting materials and other solids
- Maintains suspension over a wide temperature range
- Eliminates need for chemical activators
- Organo bentonite is easy to disperse and rapid yielding
- Suspends weighting materials and other solids
Which drilling fluids are suitable for Camp Shinning’s organo bentonite?
- All oil based drilling fluids
- Invert emulsion fluids
- Workover fluids
- Fracture fluids
1, As a manufacturer, what is Camp Shinning’s main products?
Answer: Camp Shinning’s main products include organo bentonite , organoclay rheology agent, matting agent, emulsifier and organophilic lignite. Among them,Organic bentonite clay and matting powder are mainly used in paints,coatings, inks and greases, while organo bentonite , emulsifier (Primary and secondary emulsifier) and organophilic lignite are mainly used in oilfield drilling mud and fracture fluids
2,What is the price range of organo bentonite produced by Camp Shinning?
Answer: There are many kinds of organo bentonite. According to the different raw materials and application fields, the price of Organic bentonite clay is based on the principle, and the range is very wide. Generally, the price of organic bentonite clay in oilfield mud is from USD1.5/kg to USD2.7/Kg.
And for paints,coatings, greases and inks, the Organic bentonite clay price range is from US $1.7 to US $2.4, which is only a rough range, depending on different application fields and raw materials.If you want to get the specific organic bentonite clay price, you need to tell us what is your application, or what kind of similar organic bentonite clay bentonites you used in the past, which will directly and effectively help us recommend similar quality organic bentonite clay to you.
3,What is the minimum order quantity of Camp Shinning’s organo bentonite?
In order to support our customers to vigorously promote our organo bentonite, our minimum order quantity is 500kg.It’s just a pallet.
4, What is the payment method of Camp Shinning for all orders?
We accept payment by L / C at sight and 30% TT in advance and 70% against copy B / L for all organo bentonite rheological additive bentonites exported from Camp Shinning.
Of course, for some old customers, we also accept payment CAD through bank.
5,What is the delivery time of the organo bentonite produced by Camp Shinning?
Camp Shinning’s organo bentonite usually takes 7 to 10 working days to deliver, which originates from the fact that Camp Shinning owns its own bentonite mine. It plays a great role in this process, greatly saving the time of delivery and preparation of raw materials, as well as Camp Shinning’s advanced production equipment and skilled technology. It plays a comprehensive role in the delivery.
6,How long does it take for Camp Shinning to produce organo bentonite ?
Like the above answer, the production cycle of organo bentonite produced by Camp Shinning is 5-10 working days.
7,What’s the packaging method of Camp Shinning’s organo bentonite?
The organo bentonite clay produced by Camp Shinning is packed with paper bag lined with PE film.Can greatly play the role of moisture-proof. Usually, our packing methods are 25kg, 50LB and 1 metric tons. We can also customize according to customers’ requirements.
Generally, 20 FCL can hold 16 tons with pallet, 40 fcl can hold 22 tons with pallet.
8,How long is the shelf life of the organo bentonite produced by Camp Shinning?
Generally, the shelf life of Camp Shinning’s organo bentonite clay is 24 months, if it is stored in strict accordance with the Camp Shinning requirements.
9,What is the CAS number of the organo bentonite produced by Camp Shinning?
Organo bentonite clay Cas Number is 68953 – 58 -2 , Because it is a kind of amine treated bentonite clay.
10,What’s the HS number of organo bentonite clay ?
HS number of organo bentonite clay in China, we mainly use 3824, but some abroad customers use 2508.Therefore, you can verify the correct HS number according to the specific situation of your country.Basic chemical name is modification bentonite.
11,Does Camp Shinning provide free samples of organo bentonite clay?
In order to support all potential customers to vigorously develop organo bentonite clay, Camp Shinning provides free samples for testing before big order., organic bentonite clay samples are free, but the freight should be borne by customers themselves.
12,How to get the quotation of Camp Shinning’s organo bentonite clay quickly?
Normally, Camp Shinning ’s quotation requires a reply within 8 hours. If you are in a special emergency, you can call the sales staff of Camp Shinning directly or send an email to the sales team of Camp Shinning . They will give an emergency reply as soon as they receive your inquiry.
organo bentonite sales email: email@example.com
