Organically modified hectorite clay for drilling muds and working fluids

Organically modified hectorite clay for drilling muds and working fluids in low temperature environments
Organophilic clay CP-992 additive is a moderate downhole temperature performance organoclay designed to deliver rapid dispersion and good sag resistance properties.  Organoclay CP-992 is specifically designed to provide rapid rheology build in low temperature field conditions down to 35˚F (2˚C). Under these conditions,CP-992 will effectively viscosify invert and all-oil muds formulated with diesel,mineral oil, and poly, linear and iso alpha olefins base fluids.

mailEmail: [email protected]

Product details

Organically modified hectorite clay for drilling muds and working fluids in low temperature environments

Organophilic clay CP-992 additive is a moderate downhole temperature performance organoclay designed to deliver rapid dispersion and good sag resistance properties.  Organically modified hectorite clay CP-992 is specifically designed to provide rapid rheology build in low temperature field conditions down to 35˚F (2˚C). Under these conditions,CP-992 will effectively viscosify invert and all-oil muds formulated with diesel,mineral oil, and poly, linear and iso alpha olefins base fluids.

1, Application

Base oil:

  • Diesel Oils
  • Crude Oils
  • Mineral Oils
  • Synthetic Oil
  • Alpha Olefins
  • Low BTEX base oil

Viscosifying drilling Fluids:

  • Oil based drilling fluids
  • Invert emulsion fluids
  • Workover fluidsl
  • Completion fluids
  • Casing packs
  • Packer fluids
  • Spotting fluids

2, Properties

Composition Organically modified bentonite clay

Appearance Off white to tan finely divided powder,

Moisture content (105℃,2hr) ≤3.5%

Particle size (<76μm or 200mesh) ≥98%

Specific Gravity 1.7

3, Advantages

  • Disperses easily in less time with less shear
  • High performance viscosifier for low aromatic, all mineral oil and synthetic base fluids
  • Cost- effectively builds viscosity and yield point
  • Aids control of fluid loss to the formation
  • Increases emulsion stability
  • Suspends weighting materials and other solids
  • Confers stability at the pressure and temperature 108Pa and 230℃

4, Safety

All safety information is provided in the Material Safety Data Sheets for Zhejiang Camp-Shinning New Material Co., Ltd.

5, Package

Kraft paper bag with PE liner or multi-wall paper sacks or customized. 25kg/bag or 22.68kg/bag or customized

6, Storage

Organically modified hectorite clay  CP-992 Store in a dry, well-ventilated area with temperature of 0℃-30℃. Keep container closed. The quality guarantee period is 24 months.

7, Notice

The information on use is based on data which are believed reliable, but any recommendation or suggestion made is without guarantee or warranty, since the conditions of use are outside our control. All products are sold on the conditions that purchasers shall make their own tests to determine the suitability of such products for their purpose and that all risks are assumed by user. We disclaim any responsibility for damages resulting from careless or improper handling or use. Nothing herein is to be taken as permission, inducement or recommendation to practice any patented invention without a license.

FAQ:

1) Q: What is your MOQ?

A: Normally our MOQ for each grade is 1ton. If you think it is too much, we can discuss according to your requirement in details.

2) Q: Can you offer free sample?
A: Yes, we can provide free samples of 200g – 500g.

3) Q: What is your delivery time?

A: We deliver in 7-10days.

4) Q: Can you accept mixed products in one container?
A: Yes, we can.

5. Transportation and Packing

A: By sea or By air
A: Kraft bag or kraft complex interior with PE or customized

Packing size: 25kg/bag or 500kg/bag or customize

16MT/20FCL with pallet, 18MT/20FCL without pallet

25MT/40FCL with pallet.

Products should be stored in ventilated cool and dry place.

6 What’s the application of your organoclay rheological additive?

A: Our organoclay use for paints,coatings,inks,grease lubricating and oil drilling mud.
7,How to get your quotation/Sales contact info ?
A: Pls mail us or call Mob: 0086-131 85 071 071

Our sales representatives will reply you in 24 hours about your requirements.

If you are interesting our Organically modified hectorite clay , pls mail us:

[email protected]

Cel(Whatsapp)”  86-131 85 071 071
