Organoclays for oil based drilling mud

Organophilic Clays CP-2 also named amine treated Bentonite.

In diesel oil based fluids,organophilic clay viscosifier CP-2 are used to increase carrying capacity and suspension properties, providing support for weight materials and improved cutting removal. Organophilic bentonite also aids in filter-cake formation and filtration control.

Properties

Composition  Organically modified bentonite clay

 Physical appearance  Off white to tan free-flowing powder

 Moisture content (105℃,2hr)         ≤4%

 Particle size (<76μm or 200mesh)    ≥95%

Advantages

Effective viscosifier and gellant

Aids control of fluid loss to the formation

Increases emulsion stability

Improves cuttings carrying and hole cleaning capacity

Suspends weighting materials and other solids

Confers temperature stability to the fluid

Application

Base oil:

Diesel Oils

Crude Oils

Mineral Oils

Synthetic Oil

Viscosifying drilling Fluids:

Oil based drilling fluids

Invert emulsion fluids

Workover fluids

Completion fluids

Casing packs

Packer fluids

Spotting fluids

Package

Organophilic Clay CP-2 is packed in 50lb(22.68kg) or 25kg/bag or customized,multi-wall paper sacks or Kraft paper bag with PE liner or customized.

Storage

CP-2/CP-2A Store in a dry, well-ventilated area with temperature of 0℃-30℃.  Keep container closed. The quality guarantee period is 24 months.

There are various types of organobentonite products available in the market such as CP-992, CP-150,CP-982 etc.

They may have different performance characteristics such as high gel strength and good dispersibility, which can form coarse to colloidal dispersions in oil.

Its compatibility makes it a good match for oil-based systems and can form a stable system. Organophili clay bentonite is mainly used to improve the bearing capacity of oil-based mud system and effective extraction of drill cuttings.

Compared with conventional organic clay bentonite, CP series bentonite can improve drilling efficiency, improve the rheological properties of drilling fluids, enhance the stability of drilling fluids and the ability to carry drill cuttings, thereby improving the overall effectiveness of drilling operations.

The performance of organo bentonite in different oil-based drilling fluids mainly depends on the type of base oil and the characteristics of organic bentonite it can improve the drilling fluid’s carrying capacity and the ability to effectively extract drill cuttings, improve the rheological properties, and enhance the stability of the drilling fluid.

In mineral oil-based drilling fluid, synthetic oil-based drilling fluid, synthetic oil-based drilling fluid, their performance is different.

However, organic clay bentonite can all improve the viscosity and dynamic shear of drilling fluids, can act as a thickening and rheology modifier in this environmentally friendly base fluid, and it is compatible with synthetic base fluid formulations, providing thixotropic properties and high gelling efficiency.

We sincerely welcome you to visit our factory and test our organic bentonite.After receiving your contact, we will provide you with our product specifications, free samples for you to test, and offer corresponding technical support.

Organophilic clay bentonite shows good adaptability and performance in various oil-based drilling fluids.

It selects the right organic bentonite products to optimize the performance of oil-based drilling fluids according to specific drilling environments and requirements, improving drilling efficiency and safety.Looking forward to your inquiry.
