organophilic clay filter

ORGANOCLAY CP-200

—-ORGANIC ADSORPTION MEDIA

ORGANOCLAY CP-200 is a proprietary granular media that is highly effective in

adsorbing organic compounds, particularly non-aqueous phase liquids (NAPLs),

dissolved polycyclic aromatic hydrocarbons (PAHs) and polychlorinated biphenyls

(PCBs).

APPLICATIONS:

ORGANOCLAY CP-200 is specially formulated for use in the following applications:

Organophilic Filtration Media: as flow through medla for treating groundwater and

leachate.

ORGANOCLAY Bulk Capping: provides subaqueous chemical isolation of

contaminated sediment NAPL seeps in waterways.

Permeable reactive barrier.

Solidification/Stabilization additive: improves hydraulic and leachability performance

of pozzolanic mixes by adsorbing NAPL and dissolved low solubility organics.

ADVANTAGES:

As filtration media used in series prior to activated carbon vessel, it extends life and

adsorbency of activated carbon by removal of larger molecular organics that can cause

fouling.

Operates in stand-alone mode for treatment of oil contaminated waters or steam

condensates.

12

High adsorption capacity of oiis, greasesand other NAPL.

Aid in settling through water column whenplacing bulk active in situ sediment cap.

 ORGANOCLAY CP-200 is ideal for use intermediation applications where oils.

Greases, non-aqueous phase liquids (NAPL) and other organic contaminants are

present.

TYPICAL PROPERTIES:

PACKAGE: 25kgs/bag, kraft bag or kraft complex interior with PE or customized.

NOTICE: The information on use is based on data which are believed reliable, but any

recommendation or suggestion made are without guarantee or warranty, since the conditions of use are

outside our control. All products are sold on the conditions that purchasers shall make their own tests to

determine the suitability of such products for their purpose and that all risks are assumed by user. We

disclaim any responsibility for damages resulting from careless or improper handling or use. Nothing herein

is to be taken as permission, inducement or recommendation to practice any patented invention without a

license. See MSDS for safety w before to use.
