Camp Shinning supplies oilfield additives: organophilic clay Organophilic lignite and Emulsifier, they are oilfield chemicals. Here let us introduce each oilfield additives one by one.

Organophilic Clay is an easy dispersing, self activating organoclay that exhibits high performance efficiency in diesel, low aromatic mineral oil, modified vegetable oil and synthetic base fluid formulation. CP-150 unique rheological structure suspends weighting materials and other solids with less increase in viscosity and gel strength than conventional bentonite. It is highly effective in distillate and mineral oil based invert fluids.

Organophilic lignite powder uses to replace asphalt or gilsonite to control fluid loss in any synthetic-base drilling fluid system,and is compatible with other additives.

Primary and secondary emulsifiers in oil-base mud systems. emulsifiers is formulated to give good emulsification, improved thermal stability of the invert emulsion, and enhanced high-temperature,high-pressure (HTHP) filtration control. Through comprehensive tests in a number of oil-base mud formulations with various base oils, mud densities, oil/water ratios and hot-rolling temperatures, primary and secondary emulsifiers proves that at working temperature up to 149oC (300oF), CPMUL-P can maintain high ES (electrical stability), low HTHP filtrate and desired rheological property.

Sale Dept:    [email protected]

Cell(Whatsapp): +86-13185071071

Properties

Composition                      Organic derivative of a montmorillonite clay

Appearance                       Fine powder, white

Moisture content (105℃,2hr)         ≤3.5%

Loss on ignition (1000℃)            40%-44%

Bulk density                       0.40~0.60g/cm3

Fineness (<74μm, %)               ≥99.8%

Dispersion fineness (μm)            ≤10

Advantages

• High purity, low silica content.
• Easy dispersing, fine particle size.Easy to use, no need to pregel
• High viscosity and high thixotropic.
• Wide application range. It can be applied in almost all resins and solvents
• Gel is very transparent and of light color.

Application

Oilfield chemicals Organophilic clay are used in the following applications:

• Paints including top grades paint, decorative paint, industrial paint, traffic paint etc.
• Inks
• Sealant
• Cosmetic
• Cleaning agent
• Oil Drilling Mud
• Fracture Fluids
•

Safety

All safety information is provided in the Material Safety Data Sheets for Zhejiang Camp-Shinning New Material Co., Ltd.

Package

Kraft paper bag with PE liner or multi-wall paper sacks or customized. 25kg/bag or 22.68kg/bag or customized

Storage

Thixotropic gel has a shelf life of 2 years, and should be stored in ventilated cool and dry place.

Notice

The information on use is based on data which are believed reliable, but any recommendation or suggestion made is without guarantee or warranty, since the conditions of use are outside our control. All products are sold on the conditions that purchasers shall make their own tests to determine the suitability of such products for their purpose and that all risks are assumed by user. We disclaim any responsibility for damages resulting from careless or improper handling or use. Nothing herein is to be taken as permission, inducement or recommendation to practice any patented invention without a license.

1, Are you organoclay supplier in china?

Yes, we are professional organophilic clay supplier in China.

2,  What’s your annual capacity of organic bentonite clay?

Our annual capacity of organo bentonite is 20000MT. The bentonite powder is 15000MT.

3,  Does Camp Shinning have own raw bentonite mine?

Yes, Camp Shinning organoclay has own bentonite clay powder mine in the North of China. It can better ensure the quality of our organic bentonite clay raw materials.

4, Do you have the relevant rheological agent certificate?

Yes, Zhejiang Camp Shinning New Material Co.Ltd have Certificate of ISO9001:2015 and Certification for safe transport of Chemical Goods.

 Camp Shinning organoclay is authorized as a certified supplier by the website of Made in China.

5,How many years of experience does Camp Shinning in the field of organophilic clay？

Camp Shinning organophilic bentonite have 20 years experience in the field of rheology modifier.

6, Which countries have your rheological additives mainly exported to?

Camp Shinning organoclay mainly export to Russia, Brazil, Canada, Mexico, UAE,Saudi Arabia and Kuwait etc.

Because our organoclay applications are mainly used in oil fields, there are successful cases of our organic clay bentonite powder in those markets where is a large demand for drilling fluid chemicals.

7,How many companies are there under Camp Shinning ?

Camp Shinning companies includes

Zhejiang Camp-Shinning New Material Co.Ltd (specialized in exporting rheology modifiers),

Chaoyang AutoFuLL Bentonite Co.Ltd (professional organoclay manufacturers in China) ,

 Hangzhou Camp-Shinning Co.Ltd (Focus on domestic sales of rheology additive)

  Zhejiang Camp-Shinning Electronic Co.Ltd. (An independent electronics company)

8,Can I become your organoclay distributor in our Counttry?

Yes,we welcome you to join our bentonite organoclay sales

9, Do you provide training and technical support for organic bentonite clay?

Yes,our technical department and after-sales service department will provide you with professional training and services for organoclay rheological additive.

10, Which oilfield chemicals does Camp Shinning provide?

Our oilfield chemicals include organophilic clay ,organophilic lignite , emusifier ( primary and secondary emulsifiers)

11, Which exhibitions does Camp Shinning participate in?

We mainly participate China Coating Show. OTC USA,继续添加

12,Can you provide free samples of organic clay ?

Yes，we can supply free organoclay samples. The freight should from yourside.So we need you supply us your DHL account or fedex account.

13,What’s the your min order ?

Our min order is 1MT.

14,What’s your delivery time for these clay bentonite powder ?

The delivery time about 7 to 10 working days after we receive your deposit.

15,What’s your payment terms?

Our payment terms are LC at sight or 30% TT in advance and 70% against copy BL.

16,What is your package of organic clay ? Do you supply customized package service for these organoclay?

The package:  Kraft bag or kraft complex interior with PE or customized

Packing size:  25kg/bag or 500kg/bag or customize

 16MT/20FCL with pallet, 18MT/20FCL without pallet,  25MT/40FCL with pallet.

Products should be stored in ventilated cool and dry place

15,What is organoclay ?

Organoclay also named organophilic clay,rheology modifier ,rheological additive , Organic bentonite clay and organo bentonite etc.

Organoclay CAS is 68953 – 58 -2,composition of organoclay is Organic derivative of hectorite clay.

Organoclay is a bentonite montmorillonite clay,it is good gelling agent and thixotropic agent when as paint thickener and grease thickener.When as oilfield chemicals,

 organophilic clay thickener powder is an important suspending agent and thickening agent . The rheological properties is very stable in oil drilling mud.

In terms of efficacy, organoclay can be called paint thickener, grease additive, ink additive and drilling additives and suspension agent etc.

17,  organoclay where to buy?

organoclay where to buy? Contact us is your best choice,Zhejiang Camp-Shinning New Material Co.Ltd is located in Zhejiang China.Our sales Dept:

[email protected]

Mob(Whatsapp) : 0086-19817158171

Our sales representatives will reply you in 24 hours about your requirements.

18, What is the organoclay applications?

Our organoclay applications includes organoclay for coatings,paints,organoclay grease, organoclay for oil drilling mud etc.

19,What is organoclay cas number?

Organoclay CAS 68953 – 58 -2

20,What is organoclay hs code

organoclay hs code 2508.0000

21, How many types of organic bentonite clay?

 Types of organoclay include water based organoclay (Water borne organoclay or inorganic clay ) and solvent based organoclay.

From an application perspective,it includes organic bentonite grease, rheological additives in cosmetics,rheology modifiers for waterborne paints, bentonite slurry,ink thickener (uv ink additives / printing ink additives / screen printing ink additives ) etc.

22, What is the composition of organoclay?

composition of organoclay is montmorillonite clay quaternary ammonium salt.

23, What is your organoclay price?

We have many grades of rheology modifiers, the range of organoclay price is USD1500/MT to USD2500/MT. Different application need use different organic bentonite clay.

24,What is the organoclay manufacturing process?

The organoclay manufacturing process and quality control process of organic clay is in the table as follows:

Crude bentonite ore from our mine (Pumping with water)→Bentonite slurry(purifying) → Purified bentonite slurry(Adding ammonium &other additive) → Modified bentonite slurry(filter press)→ Organoclay filter cake (drying)→ Organoclay powder (grinding)→ Organoclay powder→ Organoclay powder( packing)→ Final products organic bentonite clay

25,What organoclay activator do you recommend?

Organoclay activator, we recommend you: Methanol, ethanol, propylene carbonate, water etc.

26, How to make the pre gel and add it into the solvent based organoclay?

 In order to make good gelling agent and thixotropic agent,when use rheological additive,we suggest you make a pre gel firstly. It could keep the stable rheological properties in paint industry or grease industry or ink industry.

The steps are as follows:

1. Make a pre gel

A ,Add 85-87% sovents or mixed solvents(mix)

B,Add 5-10% Camp Shinning organoclay (Dispersing at high speed(2500rpm) for 5-10 minutes)

C, Add polar actvartor, 3-5%(Dspersing at high speed(2500rpm) for 15-20 minutes

2 Addition method of pre- gel

A, For poor-wetting capacity resin systems(epoxy, polyester, short-oil alkyd,acrylic resin atc)

 in combination with surfactant. if it can develop thixotropy structure under shear, additon process is as follows:

1. Charge resin and solents(mix)

2 Camp Shinning organoclay pre gel (mix)

3 Surfactant

4. Pigment (disperse)
5. Dilute to desired viscosity

1. For poor wetting capacity resin, non-thixotropic grind materials. if using surfactant, addition process is as follows:

1,Charge resin and solvents (mix)

2. Surfactant (if required)

3 Pigment

4. Disperse to desired fineness with grinding
5. Camp Shinning organoclay pre-gel

6 Disperse completely to desired fineness

7 Dilute to desired viscosity

27,Can you adjust your formulation as per our requestment ?
Yes,we can.Pls tell us your test method and your organoclay applications,our technical team will make an adjustment at our laboratories. Then we will supply you a full recommendation.

28,How to get your quotation, Pls tell us your Sales contact info ?

Pls mail to Camp Shinning organoclay sellers : [email protected]

Mob ( Whatsapp): 0086-19817158171

Our sales representatives will reply you in 24 hours about your requirements.

1, Where Can I Buy Emulsifier？

Zhejiang Camp Shinning New Material Co.Ltd is a emulsifier suppliers, mainly supply emulsifier. You can contact our sales dept. Email:  [email protected]

2, How to use an emulsifier?

 Using emulsifier Procedure of Mud Performance

1. Test Reagents

White oil 5#     low-aromatic-content mineral oil,

Organophilic clay CP-150 high-grade organoclay, made by Camp Shinning

Calcium hydroxide (lime)   analytical grade, from local market

CPmul-S   secondary emulsifier, made by Camp-Shinning

Barite     API grade, from local market

Rev Dust    evaluation clay, from the U.S. market

1. Test Mud Preparation

• 25% CaCl2preparation: Dissolve 25g anhydrous CaCl2into 75ml distilled water. Store it for service.
• Pour White oil5#into the mixing cup of Hamilton Beach Mixer. While stirring on the mixer at low rpm, add CPmul-P and CPmul-S, and wait until they are fully dissolved in the oil. Then at 11000rpm stirring strength, add 25% CaCl2 solution slowly into the oil. Then add other additives at the order of lime,Organophilic clay CP-150, Rev Dust and barite. When everything is added, continue to stir the mud at 11000rpm for 30 minutes.

1. Mud Performance Test

• Warm the mud to 49oC (120oF). Test R600 (dial reading at 600rpm of Fann 35 VG Meter), R300, R200, R100, R6, R3, 10-seconds gel strength and 10-minutes gel strength. Calculate Yield Point

(YP):

YP= 2xR300 – R600 (lb/100ft2)

• Hot roll the test mud in a hot roller at 121oC (250oF) for 16 hours. After hot rolling, cool the mud to 49oC (120oF), then test R600, R300, R200, R100, R6, R3, 10-seconds gel strength and 10-minutes gel strength. Calculate Yield Point (YP):

YP= 2xR300 – R600 (lb/100ft2)

• Electric Stability (ES) is tested always at room temperature. ES is tested before and after hot rolling. Before testing ES, stir the mud at 6000rpm for 10 minutes on Hamilton Beach Mixer.
• HTHP filtrate is tested after hot rolling. Test is at 121oC (250oF) and 500psi pressure differential. Collect the filtrate for 30 minutes.

3,Types of emulsifiers pdf?

We have two types emulsifiers, Primary and Secondary emulsifier.

4,Why are emulsifiers important？

Yes，emulsifiers is very important. It enhanced high-temperature,high-pressure (HTHP) filtration control. And form stable water-in-oil emulsions.Excellent electrical stability profile in oil base muds and improved thermal stability of the invert emulsion

5, Application of emulsifier?

Emulsifier is used for oil drilling mud . So it is an oil based emulsifier.

6,What is an emulsifier in chemistry?

Emulsifier in chemistry is an oil based emulsifier, the another name is industrial emulsifier,emulsifying agent and .

7, What is emulsifier hs code

emulsifier hs code: 3402

8, What is a good emulsifier

 Good emulsifier could enhanced high-temperature,high-pressure (HTHP) filtration control. And form stable water-in-oil emulsions.Excellent electrical stability profile in oil base muds and improved thermal stability of the invert emulsion
