How to Test Organoclay Suspension in paints & Coatings?

Organoclay Suspension Test Method for Coatings | Anti-Settling Performance Evaluation (CP-10).

What is Suspension Performance in Coatings?

In coating and paint systems, suspension performance refers to the ability of a formulation to prevent pigment and filler settling during storage.

A high-performance organoclay forms a stable three-dimensional gel structure, which helps:(How to Test Organoclay Suspension)

• Keep pigments uniformly dispersed
• Prevent hard sediment formation
• Maintain consistent viscosity over time

For formulators, suspension performance is a key factor affecting storage stability and application consistency.

Scope of This Suspension Test Method (How to Test Organoclay Suspension)

This test method is specifically developed for evaluating the anti-settling performance of Organoclay CP-10 in coating systems.

It is applicable to:

• Solvent-based coatings
• Industrial paints
• Pigment dispersion systems

👉 This method introduces 12-hour suspension volume measurement (ml/12h) as a practical indicator of stability.

👉 Traditional viscosity tests (such as xylene viscosity) are not sufficient alone to evaluate long-term suspension behavior in coatings.

Technical Specification for Coating Application

Reference:
Standard sample suspension value: 48 ml/12h

Suspension Test Method for Coatings (CP-10) (How to Test Organoclay Suspension)

Equipment

• 100 ml graduated cylinder (accuracy 0.01 ml)
• High-speed disperser
• Electronic balance (accuracy 0.001 g)

Materials

• Solvent (e.g., WS-3040 or equivalent coating solvent)
• 95% Methanol (activator)
• Standard Organoclay CP-10 sample

Step 1: Preparation of Organoclay Gel

• Add 98 g solvent into a container
• Slowly add 1% organoclay under 1000 rpm, disperse for 2 minutes
• Add 1% methanol activator
• Increase speed to 1500 rpm, mix for 10 minutes

👉 After dispersion, cool to 20–25°C

Step 2: Static Suspension Test

• Transfer the dispersion into a 100 ml cylinder to 50 ml mark
• Seal and keep on a stable surface without vibration
• Record suspension volume after 4, 6, and 12 hours

👉 The 12-hour suspension volume (ml) is used as the final result

Acceptance Criteria

• Acceptable range: 43–48 ml/12h
• Compare with standard sample to ensure consistency

Appearance Evaluation

• Place sample and standard sample powders on white paper
• Flatten evenly
• Observe under natural light

👉 Color should be consistent between batches

Why Suspension Performance Matters in Coatings

In real coating applications, poor suspension leads to:

• Pigment settling during storage
• Hard sediment difficult to redisperse
• Color inconsistency
• Reduced shelf life

Using high-quality organoclay like CP-10 helps achieve:

✔ Excellent anti-settling performance
✔ Stable viscosity over time
✔ Improved storage stability
✔ Better application consistency

Suspension vs Viscosity: What’s the Difference?

Many formulations rely only on viscosity testing, but:

• Viscosity = flow resistance under shear
• Suspension = stability under static conditions

👉 A coating can have high viscosity but still suffer from pigment settling.

That’s why suspension testing provides a more realistic evaluation of long-term stability.

Quality Control & Production Requirements （How to Test Organoclay Suspension?)

• All batches must meet 43–48 ml/12h suspension range
• Products outside this range are not released

If there are changes in:

• Raw materials
• Production process

👉 Customer validation is required before shipment

CP-10 is a kind of organo clay rheological additive. It is used in systems of non-polar to medium polarity aliphatic and other solvents (ketones, ester, ether esters, alcohols, aromatic).

Properties

Composition                      Organic derivative of a montmorillonite clay

Appearance                       Fine powder,white

Moisture content (105℃,2hr)         ≤3.5%

Loss on ignition (1000℃)            30%-34%

Bulk density                       0.35~0.45g/cm3

Fineness (<74μm, %)               ≥98%

Dispersion fineness (μm)            ≤40

Advantages

• High efficiency
• The gel is of light colour and high clarity
• Easy to use, no need to pregel
• Eliminate polar activator
• Consistent development of rheology
• Can be used to post correct

Application

 CP-10 is used in the following applications:

• Paints
• Putty
• Sealants &adhesives
• Inks
• Cosmetic
• Nano-composite

Need Organoclay for Coatings?How to Test Organoclay Suspension?

We supply high-performance organoclay for coatings and paints, designed for excellent suspension and anti-settling behavior.

👉 Contact us for samples, formulation support, or technical data.

Email:  [email protected]

Whatsapp: 0086-13185071071

How to Test Organoclay Suspension?we hope our info could helpful with you.

Organoclay Anti-Settling Agent

Organoclay Suspension CP-10  Performance: 12-Hour Anti-Settling Test Results
Why Suspension Matters in Coating Formulations
In water-based and solvent-based coating systems, pigment settling and filler separation are among the most common quality issues manufacturers face. When particles settle during storage or transport, it leads to:

Inconsistent product viscosity batch to batch
Color variation in final applications
Poor film formation and uneven coverage
Customer complaints and product returns
Suspension stability is critical for maintaining rheological control throughout the product lifecycle—from manufacturing to end-user application.

Our Organoclay Anti-Settling Agent CP-10 Organoclay Suspension Test
To verify the anti-settling performance of our organoclay CP-10, we conducted a controlled 12-hour suspension test using industry-standard procedures.

Test Method
Gel Ratio:

WS-3040 (Solvent): 98g
Organoclay Anti-Settling Agent CP-10: 1g
95% Methanol: 1g%
Procedure:

Add Organoclay Anti-Settling Agent CP-10 while stirring at 1000 rpm
Disperse for 2 minutes
Add methanol as polar activator
Mix thoroughly at 1500 rpm for 10 minutes
Transfer 50 ml dispersion into 100 ml graduated cylinder
Observe and record suspension volume at 2h, 4h, 6h, and 12h intervals
Test Results
Sample Batch No. 2h 4h 6h 12h Notes
CP-10 20230923 38 ml 34 ml 37 ml 38 ml —
CP-10 251218 44 ml 46 ml 43 ml 42 ml —
CP-10 25022101 35 ml 34 ml 32 ml 31 ml vs B38 Standard
CP-10 25081001 50 ml 50 ml 48 ml 48 ml —
CP-10 2602253# 40 ml 38 ml 37 ml 36 ml —

Key Findings
1. Excellent Long-Term Suspension Stability
After 12 hours of standing, our CP-10 organoclay maintained suspension volumes ranging from 31-48 ml out of the initial 50 ml dispersion.

Organoclay Anti-Settling Agent

This demonstrates:

Minimal settling over extended periods
Consistent rheological behavior throughout storage
Superior anti-sagging performance in vertical applications
2. Batch-to-Batch Consistency
All tested batches showed stable suspension performance:

Sample 25081001: Best overall—maintained 48 ml (96% retention) after 12 hours
Sample 251218: Strong performance—42 ml retention with slight fluctuation
All samples showed less than 20% volume change from initial readings
3. Comparison with Industry Standard
Sample 25022101 was tested alongside B38 industry standard. The results show our Organoclay Anti-Settling Agent CP-10 performs comparably to established market benchmarks, with consistent thixotropic response and suspension stability.

What This Means for Your Coatings
Applications Where Suspension Matters Most
Organoclay CP-10 provides essential rheology modification for:

Organoclay Anti-Settling Agent

Application Benefit
Architectural Paints Prevents pigment settling during storage
Industrial Coatings Maintains consistent viscosity in high-solids formulations
Wood Coatings Ensures uniform film formation
Metal Primers Keeps anti-corrosion pigments suspended
Decorative Paints Prevents color separation and shading variations
Formulation Recommendations
For optimal suspension performance in your coating systems:

Addition Level: 0.5-2.0% depending on desired viscosity

Mixing Protocol:

Add CP-10 at 1000 rpm under shear
Increase to 1500 rpm for full dispersion
Maintain mixing for 10-15 minutes
Add polar activator (methanol or water) if required
Compatibility: CP-10 works in solvent-based, alkyd, and modified coating systems

Technical Specifications: CP-10 Organoclay
Property Value
Appearance Light cream powder
Moisture ≤3.0%
Particle Size ≤75 μm
Bulk Density 400-600 g/L
Application Solvent-based coatings, inks, adhesives
Addition Level 0.5-2.0%
Activation Polar activator recommended
Quality Assurance
Every batch of Camp-Shinning CP-10 undergoes rigorous suspension testing before release. Our quality control process includes:

12-hour suspension protocol (industry standard: 4-6 hours)
Color consistency verification against reference standards
Particle size distribution analysis
Rheological performance testing
Conclusion
The 12-hour suspension test results confirm that our organoclay CP-10 delivers reliable anti-settling performance across multiple production batches. With 96% suspension retention in the best-performing sample and consistent results across all batches, CP-10 provides:

✓ Long-term storage stability
✓ Batch-to-batch consistency
✓ Superior rheological control
✓ Compatible with various coating systems

Get Started with Camp-Shinning
Contact us for:

Free CP-10 samples for your testing
Technical support for formulation optimization
Custom grade development for specialized applications
