Organic bentonite CP-982S for oil well

CP-982S Organophilic Clay is a moderate temperature performance amine-treated Bentonite. It is a cost-effective product, particularly in all-oil, invert diesel and mineral oil based fluids, where sufficient shear is available to achieve full dispersion. CP-982S viscosifier is used to increase carrying capacity and suspension properties, providing support for weight materials and improved cutting removal.

Properties

Composition                       Organically modified bentonite clay

Appearance                       Off white to tan free-flowing powder

Moisture content (105℃,2hr)         ≤4%

Particle size (150 mesh)              ≥98%

Specific Gravity                     1.7

Bulk Density, kg/m³                           500

30% Diesel Oil Gel, 600rpm, CP       ≥30

30% Diesel Oil Gel, Yield Point        About 8

Advantages

Effective viscosifier and gellant

Aids control of fluid loss to the formation

Increases emulsion stability

Improves cuttings carrying and hole cleaning capacity

Suspends weighting materials and other solids

Confers temperature stability to the fluid

Application

Base oil:

Diesel Oils

CrudeOils

Mineral Oils

Synthetic Oil

Viscosifying drilling Fluids:

Oil based drilling fluids

Invert emulsion fluids

Workover fluids

Completion fluids

Casing packs

Packer fluids

Spotting fluids

Package CP-982S Store in a dry, well-ventilated area with temperature of 0℃-30℃.  Keep container closed.

Storage

Kraft paper bag with PE liner or multi-wall paper sacks or customized. 25kg/bag or 50LB/Sack or customized
