Bentonite Gelling Agent in Light Weight Cement Slurry

Bentonite Gelling Agent in Light Weight Cement Slurry CP-2

Bentonite Gelling Agent in Light Weight Cement Slurry CP-2

Bentonite Gelling Agent in Light Weight Cement Slurry CP-2 evaluation with accordance API 13A Spec. Viscometer dial reading at 600R/Min. 20 Yield point /plastic viscosity ration max 3 filtrate volume max 15cm3.

Residue of diameter greater than 75 micro/m max. Mass fraction 4%. To be packed in multi-wall with one-layer water-resistant bags.

Package: Bentonite Gelling Agent in 25kg (55LB) Bags.Each 40 bag in a big bag made from a kind of waterproof tarpaulin with a resistance handle).

Palletized on reinforced PVC pallets & shrink-covered.

Bentonite Gelling Agent in Light Weight Cement Slurry CP-2

Bentonite Gelling Agent in Light Weight Cement Slurry CP-2

Bentonite Gelling Agent CP-992 Organophilic Clay is a wet process improved viscosifier and gelling agent.

It is an easy dispersing, rapid yielding organoclay that exhibits high performance efficiency in diesel oil, crude oil, Low BTEX base oil, mineral oil and synthetic containing base fluid formulation.

Bentonite Gelling Agent is stable and has good suspension and thixotropic features. It can also be used in adhesives and sealant.

Properties

Composition                      Organically modified bentonite clay

Appearance                       Off white to tan finely divided powder,

Moisture content (105℃,2hr)            ≤3.5%

Particle size (% Thru150Mesh:95min)    ≥95%

LoI:                                  35-39%

Advantages

  • Disperses easily in less time with less shear
  • High performance viscosifier for low aromatic, all mineral oil and synthetic base fluids
  • Cost- effectively builds viscosity and yield point
  • Aids control of fluid loss to the formation
  • Increases emulsion stability
  • Suspends weighting  materials and other solids
  • Confers stability at the pressure and temperature 108Pa and 230℃

Application

  • Grease
  • Oil Drilling Mud

Package

Kraft paper bag with PE liner or multi-wall paper sacks or customized. 25kg/bag or 22.68kg/bag or customized

Storage

CP-992 Store in a dry, well-ventilated area with temperature of 0℃-30℃.  Keep container closed. The quality guarantee period is 24 months.

QC Specification/ Performance Specification

项目Index

技术要求Specification

检验结果Spec Notes

外观Appearance

Gray or Tan powder

Gray powder

水份Moisture content, (105℃,2hr),%

≤4

3.5

粒度Particle size, % Thru 150 Mesh

≥98

99

粘度(3%柴油), Viscosity(3% Diesel Oil 600 rpm) CP

≥24

25

3.理化指标Typical Properties

比重Specific Gravity

1.7

堆密度Bulk Density, KG/ M³

540

溶于水Soluility in Water

Insoluble

溶于油Solubility in Oil

Dispersible

气味Odor

Mild

5.测试结果Test Result

测试结果Test Result: PASS

检验人员 Inspector:

Organophilic clay China Coating Show

 Organophilic clay China Coating Show

In December 2024, we participated in the 2024 China International Coatings Exhibition. This is the largest professional coatings exhibition in the world. Many suppliers and buyers of raw materials for paints and coatings gathered in Guangzhou for exchanges and communication. We also brought our professional organic bentonite to the exhibition, and some of our new specifications were exhibited at the exhibition booth, which was welcomed and interested by many exhibitors.

 Organophilic clay China Coating Show

The new formula of organic bentonite we brought has the ability of easy dispersion and high-quality thixotropy. It has been widely welcomed in the application of paints and coatings, greases and inks. At the same time, we are very professional in applying organic bentonite to oilfield drilling mud, which has also been sought after by some overseas customers.

 Organophilic clay China Coating Show

In 2025, we will continue to participate in the China International Coatings Exhibition held in Shanghai, and will meet and discuss with our new and old customers. At the same time, we will also bring newer models to the exhibition.

What are the applications of Organoclay | Organophilic Clay

What are the applications of Organoclay | Organophilic Clay

 The applications include:

Sealants

Oil based drilling fluids (OBM)

Adehesives

 water based Paints/Coatings

Lubricanting Grease

Inks

Solvent Based Paints and Coatings

Dry Mix Motar

Waste Water Treatment



Organoclay Bentonite

Organoclay Rheological Additive

Organophilic clay

What are the applications of Organoclay | Organophilic Clay

What are the applications of Organoclay | Organophilic Clay

We supply some grades are economic pre-gel grade, low viscosity,high sag resistance. For low to middle polarity.

We also supply high temperature tolerance grade for OBM.High purity and high temperature stability.Those grades could use for solvent based and water based system,For high polarity like ethylacohol.

Elementor #27347

Rheological modifiers clay

In exploring the field of efficient gelling of organic liquids with low and medium polarity, clay rheology modifiers ensure that pigments and fillers float in the liquid with extraordinary suspending power, effectively resisting the challenge of hard settling.

Density and Moisture: A density of 1.75g/cm³ with a moisture content of ≤3.5% (@105°C, 2 hours) ensures a stable and pure product.

The recommended proportion of polar activator (e.g. 95% ethanol, methanol, acetone or propylene carbonate) is 30%-50% by weight of the organobentonite, but the optimum proportion needs to be precisely determined experimentally to avoid under- or over-development of viscosity.

It not only exhibits excellent gelling efficiency in these media, but also maintains impressive thickening properties over a wide temperature span, and its viscosity is among the best in the industry.

Rheological modifiers clay

Rheological modifiers clay

Organophilic Clay Chemistry Type

Organophilic Clay Chemistry Type

Zhejia ng Camp-Shinning New Material CO.,LTD is a professional manufacturer of Organophilic Clay Chemistry Type under the umbrella of Camp Shinning. It is a comprehensive company that integrates research and development, production, sales, and technical services.

At present, our organoclay bentonite has been modified and exported to more than 40 countries worldwide, including Europe, the Middle East, North America, South America, and Southeast Asia.We have more than 20 years of experience in the field of organophilic clay bentonite, and the quality of our products is strictly controlled. We have passed ISO9001 quality system certification and ISO14001 management system certification. In the European market, we have successfully gained REACH Certification.

At the same time, we have also obtained patents for organo clay bentonite products.

Our organic clay bentonite has achieved great success in various application directions in the industrial field. It can not only be applied to paint coatings, ink lubricants, oilfield drilling, but also in the  inorganic  system, which is a water-based system, it can also be applied to water-based paint coatings and water-based ink lubricants.

Our annual production capacity has reached 20000 tons.In the entire industry, we have taken the lead in achieving a fully ecological supply chain system, including raw ore mining, production preparation, quality control research and development, testing and after-sales service.

Organophilic Clay Chemistry Type

Organophilic Clay Chemistry Type

Organophilic Clay Chemistry Type

Russia NEFTEGAZ | Booth No. 74C56 | Organoclays For oil drilling

Organoclays For oil drilling

Russia NEFTEGAZ | Booth No. 74C56 | Organoclay For oil drilling

Organoclays For oil drilling : This time we took our organic bentonite to the Russian Oil and Gas Exhibition. At the exhibition, we met and negotiated with many new and old customers. Finally, we learned that our organic bentonite has received a lot of attention in the Russian market. Big welcome, especially in terms of price and quality.

With this we will continue to participate in the exhibition in 2025. Bringing maximum convenience to our customers in Russia and users in surrounding countries.

Russia NEFTEGAZ | Booth No. 74C56 | Organoclay For oil drilling

Organobentonite has always been popular with oilfield drilling users because it has good suspension, thickening and thixotropy properties. Repeated experiments by users have proven that the product can be used boldly. At present, our annual sales volume of organic bentonite in Russia is extremely huge, which is why local users in Russia are generally very receptive to our products.

Russia NEFTEGAZ | Booth No. 74C56 | Organoclay For oil drilling

Organobentonite is also known as a suspending agent, thickening agent, and anti-settling agent. It is applied to different industrial fields according to different performances. For example, in the paint and coatings industry, organic bentonite is used as a thixotropic agent and anti-settling agent. In oil field drilling mud, organic bentonite is used as a suspending agent.
