The Organoclay bentonite | Organophilic clay -specialized Zhejiang Camp-Shinning New Material CO.,LTD.
and Hangzhou Camp-Shinning CO.,LTD. are subsidiaries of Camp-Shinning. Camp-shinning concentrated on high value-added, high-technology organo bentonite series products, particularly in research, development, manufacturing, and sales of organic (solvent based organoclay) and inorganic bentonite (water based organoclay). Our Organophilic bentonite clay finds widespread application in oil drilling mud, paint, coating, lubricating grease, adhesive, construction mortar, cosmetics, and waste water treatment, among other applications. A group of world-class professional users and distributors, such as SUN CHEMICAL,,SIEGWERK,LEHMANN &VOsS, and others, have acknowledged our dependable quality.
Current annual production of organic bentonite clay | organoclay is 20,000 metric tons, while refined bentonite production is 15,000 metric tons. Our ISO 9001 quality system certification and IS014001 environmental management system certification, as well as our own mine with superior ore quality and production of proprietary technology, ensure the long-term quality and supply stability of our Organoclay bentonite | Organophilic clay.
Our mission is to provide users with superior Organoclay bentonite | Organophilic clay and services and to collaborate with them to achieve success and glory. Internet address: https://www.rheologicaladditive.com/ and email address: [email protected]
Whatsapp / Wechat: +86-13185071071
organophilic clay chemistry
Organoclay | Organophilic Clay CP-2 also named amine treated Bentonite.
In diesel oil based fluids,organophilic clay viscosifier CP-2 are used to increase carrying capacity and suspension properties, providing support for weight materials and improved cutting removal. Organophilic bentonite also aids in filter-cake formation and filtration control.
Properties
Composition Organically modified bentonite clay
Physical appearance Off white to tan free-flowing powder
Moisture content (105℃,2hr) ≤4%
Particle size (<76μm or 200mesh) ≥95%
Specific Gravity 1.6-1.8
Advantages
Effective viscosifier and gellant
Aids control of fluid loss to the formation
Increases emulsion stability
Improves cuttings carrying and hole cleaning capacity
Suspends weighting materials and other solids
Confers temperature stability to the fluid
Application
Base oil:
Diesel Oils
Crude Oils
Mineral Oils
Synthetic Oil
Viscosifying drilling Fluids:
Oil based drilling fluids
Invert emulsion fluids
Workover fluids
Completion fluids
Casing packs
Packer fluids
Spotting fluids
Package
Organoclay | Organophilic Clay CP-2 is packed in 50lb(22.7kg) or 25kg/bag or customized,multi-wall paper sacks or Kraft paper bag with PE liner or customized.
Storage
CP-2 Store in a dry, well-ventilated area with temperature of 0℃-30℃. Keep container closed. The quality guarantee period is 24 months.
Notice
The information on use is based on data which are believed reliable, but any recommendation or suggestion made is without guarantee or warranty, since the conditions of use are outside our control. All products are sold on the conditions that purchasers shall make their own tests to determine the suitability of such products for their purpose and that all risks are assumed by user. We disclaim any responsibility for damages resulting from careless or improper handling or use. Nothing herein is to be taken as permission, inducement or recommendation to practice any patented invention without a license.
Internet address: https://www.rheologicaladditive.com/ and email address: [email protected]
Whatsapp / Wechat: +86-13185071071
Organoclay | Organophilic Clay
Many users who purchase organophilic clay chemistry, whether they apply organophilic clay to paint or coating fields or oil field drilling, often ask how to use organo clay bentonite.As a professional producer and manufacturer & supplier of organophilic clay, we have accumulated a lot of experience in the past 20 years of export, especially in the application and use of organo bentonite , which can greatly help our customers save time and explore this process.
At present, no matter which field has the foundation, our most common use methods are mainly divided into two types: one is to use the pre gel, and the other is to add dry powder directly.
Now we will give a detailed description of the above mentioned methods of adding dry powder directly or doing operation teaching.
Whether it is the organophilic clay chemistry produced by wet method or the organo clays bentonite produced by dry method, the general use methods are the two use methods we mentioned just now, that is, the dry powder is directly added or used as a pre gel.
When using the method of using pre gel of organoclay, In the poor and weak resin system of Humidity., if you use the specialty organophilic clay product of CP series, the dispersion and mutation of the organophilic clays chemistry will be better. However, you must make the organophilic clay type of CP series into a pre gel before using it.
一),Now let’s explain the preparation process of gel in detail.
1), First, mix 84~87% of the volume or mixed solvent together.
2),Stir 8%~10% of cp series organophilic clay chemistry at high speed for about 5~10 minutes.
3),We suggest that you use polar additives, that is, activators for high–peed stirring for 5~10 minutes, which is about 3~5% of the whole formula.
二),How to use the dry powder directly | organophilic clay chemistry.
For systems with good dispersivity, we suggest you directly add our organophilic clay chemistry dry powder, which is very convenient. Of course, if you add polar activators, such as methanol, propylene carbonate, etc., they are very recommended.
We suggest that you :
1),first mix the solvent system,
2),then directly add the organo bentonite clay powder into the mixture. They stir at a high speed within 10–5 minutes.
3), add polar activators, such as propylene carbonate or ethanol, so that they can stir for 5–0 minutes at a high speed.
4),Finally, add pigments, and then stir at a high speed again, so that they have a better mixture.
Remark We specially remind you to be willing when using organophilic clay chemistry. The organic bentonite clay of cp series is fully and completely dispersed during mixing.
Here we would like to emphasize the main reasons that affect the combination of organophilic clays chemistry dispersion.
A,Organo clays bentonite and solvent have a certain scope of adaptation. Therefore, when you use organic bentonite, or when you select the corresponding organic bentonite model, the first thing to consider is to select the corresponding organic bentonite model according to the financing polarity or solubility parameter of your formula.
B,The use of polar additives must be appropriate.Because polar activator can promote the dispersion of organophilic clays in the whole formula.In order to ensure the hydrogen bond strength of CP series organobentonites, because excessive or insufficient will affect their fluidity, we generally use 2.5 ~ 3.5% of the total amount of gel, that is, 30 ~ 50% of organobentonites.
C,Proper shearing force, shearing action and time will affect the dispersion performance of organic modified bentonite to a certain extent. The recommended shear rate is 1.2~1.7 meters per second, and the time is 10~20 minutes.
D,Try to avoid the interference of other chemicals on the dispersion ofrheology modifiers bentonite.
E,The addition amount of organo clay bentonite is generally recommended to be 0.2~2.0%. As for your formula, we hope you can determine your specific use amount through experiments.
F,The shelf life of CP series organophilic clay chemistry is two years, but its best service life is one year, and it is not affected by moisture. It should not be placed in an environment above 60 ℃.
When using organophilic clay chemistry in your formula, we recommend the following activators.
1) Methanol.
2) Propylene carbonate.
3) Ethanol
As for how to use organo bentonite clay, in the specific formula and in your specific practice, if you encounter any problems, please contact us at any time. As a professional organoclay | organophilic clay manufacturer and supplier, the promotion of organic bentonite clay is our unshirkable responsibility and obligation. We are willing to provide you with the greatest help to make your project more smoothly.
At present, Camp Shinning has gained a lot of practical experience in the field of oilfield drilling, paint and coating, printing ink and grease. We welcome you to contact us for more valuable information bout organophilic clay chemistry.
We look forward to your inquiry.
