Oil drilling organoclay CP-E23 is a kind of organo clay rheological additive. Especially organophilic clay is recommended to be applied in medium polarity and high polarity system including aromatic and aliphatic solvent.
organoclay for oil drilling
Properties
Composition Organic derivative of a montmorillonite clay
Appearance Fine powder, light yellow
Moisture content (105℃,2hr) ≤3.5%
Loss on ignition (1000℃) 35%-37%
Bulk density 0.40~0.60g/cm3
Fineness (<74μm, %) ≥99%
Dispersion fineness (μm) ≤10
Advantages
Easy dispersing, fine particle size
High purity and low silica content
High viscosity and thixotropy
Eliminate polar activator in medium and high polarity solvent
Wide application range. It can be applied in almost all resins and solvents
Application
Rheological additive CP-E23 is used in the following applications:
Paints including decorative paint, industrial paint
Grease
Inks
Oil drilling mud
Cleaning agent
Oil putty
Using
Modifier rheology CP-E23 can be added directly in powder under high shear condition. The addition is recommended to be before grinding procedure to get the best effectiveness. Addition level is commonly 0.2%~1.0%. In low polarity system such as mineral spirit, if polar activator is added, better efficiency can be achieved.
Dosage of polar activator is suggested to be 10%-20% of CP-E23 by weight
Safety
All safety information is provided in the Material Safety Data Sheets for Zhejiang Camp-Shinning New Material Co.,Ltd..
Package
Kraft paper bag with PE liner or multi-wall paper sacks or customized. 25kg/bag or 22.68kg/bag or customized
Storage
Rheological additive CP-E23 has a shelf life of 2 years, and should be stored in ventilated cool and dry place.
Notice
The information on use is based on data which are believed reliable, but any recommendation or suggestion made is without guarantee or warranty, since the conditions of use are outside our control. All products are sold on the conditions that purchasers shall make their own tests to determine the suitability of such products for their purpose and that all risks are assumed by user. We disclaim any responsibility for damages resulting from careless or improper handling or use. Nothing herein is to be taken as permission, inducement or recommendation to practice any patented invention without a license.
We are now looking for Global Distributors, Welcome to cooperate with us !
⇒ You are welcome to send us an email to know the latest information about organophilic clay.We would like to send you the latest catalogue, or free rheological additive samples for testing.
Good viscosifier rheology modifier organoclay,CP-992 is an easy dispersion formulation of organophilic clay developed for use with drilling oil-based muds, invert emulsions muds, completion,packer and workover fluids as a viscosifier, filtration control and anti-settling additive, offering cost effective performance.1, Properties of viscosifier rheology modifierComposition Organically modified bentonite clayAppearance Off white to tan finely divided powder,Moisture content (105℃,2hr) ≤3.5%Particle size (<76μm or 200mesh) ≥98%Specific Gravity 1.72, Advantages
Disperses easily in less time with less shear
High performance viscosifier for low aromatic, all mineral oil and synthetic base fluids
Cost- effectively builds viscosity and yield point
Aids control of fluid loss to the formation
Increases emulsion stability
Suspends weighting materials and other solids
Confers stability at the pressure and temperature 108Pa and 230℃
4,SafetyAll safety information is provided in the Material Safety Data Sheets for Zhejiang Camp-Shinning New Material Co., Ltd.5,PackageKraft paper bag with PE liner or multi-wall paper sacks or customized. 25kg/bag or 22.68kg/bag or customized6,Storageviscosifier rheology modifier organoclay CP-EZ Store in a dry, well-ventilated area with temperature of 0℃-30℃. Keep container closed. The quality guarantee period is 24 months.7, NoticeThe information on use is based on data which are believed reliable, but any recommendation or suggestion made is without guarantee or warranty, since the conditions of use are outside our control. All products are sold on the conditions that purchasers shall make their own tests to determine the suitability of such products for their purpose and that all risks are assumed by user. We disclaim any responsibility for damages resulting from careless or improper handling or use. Nothing herein is to be taken as permission, inducement or recommendation to practice any patented invention without a license.For organoclay technical support, price inquiry, please contact us [email protected] Tel: 0086-131 85 071 071
Heat Resistance and Salt Tolerance Polymer for Fluid Loss Control
Polymer is a powdery polymer. Fluid Polymer with white to light-yellow appearance was polymerized by heat resistance and salt tolerance allyl monomers. It provides better rheology regulation and fluid loss control. The product has some advantages as follows:
low viscosity effect in mud by special molecular structure;
superior function in fresh mud and brine mud;
Better heat resistance in fluid loss system;
Perfect anti-sloughing and clay hydration control performance.
Performance evaluation
Rheology and fluid loss
table1 rheology and fluid loss
mud type
hot rolling
150℃×16h
AV
mpa.s
FL
mL
4%NaCl
before hot rolling
21
7.4
after hot rolling
15
10.2
saturated brine
before hot rolling
22
8.0
after hot rolling
16
10.4
*Brine+10% benonite+0.3%NaCO3+2%polymer product.
Anti-sloughing and clay hydration control performancetable2 anti-sloughing and clay hydration control performance
Organic bentonite Rheological additive is a kind of traditional organic ammonium montmorillonite organoclay, which is applicable to aliphatic and aromatic system of low-medium polar solvent, such as mineral oil, paraffin oil, toluene, xylene, 200# solvent oil systems.
This grade is mainly recommended for use in oilfield drilling fluid systems, especially in formulations based on diesel oil, mineral oil, or synthetic oil. Our organoclay provides excellent suspension and rheological properties in such oil-based mud systems, ensuring outstanding system stability. It also performs exceptionally well in high-pressure fluid systems. With its superior adaptability and stability, this oilfield chemical is highly recognized and favored by drilling service companies.
2,Application:
Organoclay, as a kind of thickening, anti-sinkable, anti-sagging and thixotropy additive, is widely used in industrial paint, terrace paint, casting paint, atomic ash, adhesive, grease, etc.
3,Usage:
Organophilic clay can disperse at normal temperature. Pre-gel is suggested to make out of it and, added before grinding. High shearing equipments should be adopted so as to achieve the best dispersible effect.Modified bentonite can be dispersed completely with polar activator including: carbonic acid allethrin, methanol/water (95/5), ethanol/water (95/5)or acetone. The best dosage of polar activator can be changed according to different systems, usually 30-50% of the organoclay rheological additive.
4,Dosage of organic bentonite Rheological additive
Organic modifier dosage in the system is usually 0.5-2.0% (percentage in weight).
7,Package & Storage of Organic bentonite Rheological additive
Kraft paper bag interior with PE.
The weight : 25±0.25kg per bag.The package and weight also can be customized.
Product should be stored in ventilated, cool and dry place.
8,Storage life : two years.
9,Notice
The information on use is based on data which are believed reliable, but any recommendation or suggestion made is without guarantee or warranty, since the conditions of use are outside our control. All products are sold on the conditions that purchasers shall make their own tests to determine the suitability of such products for their purpose and that all risks are assumed by user. We disclaim any responsibility for damages resulting from careless or improper handling or use. Nothing herein is to be taken as permission, inducement or recommendation to practice any patented invention without a license.
We are now looking for Global Distributors, Welcome to cooperate with us !
⇒ You are welcome to send us an email to know the latest information about organophilic clay.We would like to send you the latest catalogue, or free rheological additive samples for testing.
Organoclay for oil drilling bentonite CP-160 is an easy dispersing, self activating Organophilic Clay. Rheological additive exhibits high performance efficiency in diesel, low aromatic mineral oil, modified vegetable oil and synthetic base fluid formulation.
Modified bentonite CP-160 unique rheological structure suspends weighting materials and other solids with less increase in viscosity and gel strength than conventional bentonite. rheology modifier is highly effective in distillate and mineral oil based invert fluids.
Organoclay for oil drilling bentonite
Properties
Composition Organically modified bentonite clay
Appearance Off white to tan finely divided powder,
Moisture content (105℃,2hr) ≤3.5%
Specific Gravity 1.7
Bulk density 0.40~0.60g/cm³
Advantages
Effectively suspends weighting materials and other solids
Maintains suspension over a wide temperature range
Eliminates need for chemical activators
Is easy to disperse and rapid yielding
Suspends weighting materials and other solids
Maintains suspension over a wide temperature range
Application
organoclay rheological additiveCP-160 is a self-activating gallant offering rapid yield development, high gel strengths, and increased efficiency. The unique properties of CP-160 are especially valuable in low-shear mud plant operations and during completion fluid manufacture at the well site
Base oil:
Diesel Oils
Mineral Oils
Synthetic Oil
Linear and isomerized Alpha Olefins
Modified vegetable oil
Viscosifying drilling Fluids:
All oil based drilling fluids
Invert emulsion fluids
Workover fluids
Fracture fluids
Safety
All safety information is provided in the Material Safety Data Sheets for Zhejiang Camp-Shinning New Material Co., Ltd.
Package
Kraft paper bag with PE liner or multi-wall paper sacks or customized. 25kg/bag or 22.68kg/bag or customized
Storage
Organic bentonite CP-160 | thixotropic agent store in a dry, well-ventilated area with temperature of 0℃-30℃. Keep container closed. The quality guarantee period is 24 months.
Notice
The information on use is based on data which are believed reliable, but any recommendation or suggestion made is without guarantee or warranty, since the conditions of use are outside our control. All products are sold on the conditions that purchasers shall make their own tests to determine the suitability of such products for their purpose and that all risks are assumed by user. We disclaim any responsibility for damages resulting from careless or improper handling or use. Nothing herein is to be taken as permission, inducement or recommendation to practice any patented invention without a license.
Lubricant Additives : Organoclay use for lubricating grease
Organoclay Bentonite Grease in Lubricants
Lubricant Additives : Organoclay use for lubricating grease
Organoclay use for lubricating grease CP-250A
Organoclay CP-250A is a kind of purified and modified organoclay rheological additive, designed especially for using in Grease based on synthetic oils | Mineral oil | Medium,high viscosity lubricating oil. As a grease additive,organophilic clay CP-250A has high gelling efficiency, fine thixotropy and perfect anti-settling.
Organoclay for grease
Organoclay use for lubricating grease : Properties
Composition Organic derivative of a montmorillonite clay
Appearance Fine powder, light yellow
Moisture content (105℃,2hr) ≤3.5%
Loss on ignition (1000℃) 34%-36%
Bulk density 0.42g/cm3
Fineness (<74μm, %) ≥98%
Organoclay use for lubricating grease : Advantages
High efficiency
The gel is of light colour and high clarity
Easy to use, no need to pregel
Eliminate polar activator
Consistent development of rheology
Can be used to post correct
Organoclay use for lubricating grease
Organoclay use for lubricating grease : Application
CP-250A is used in the following applications:
Grease Lubricant(the base oil is synthetic oil such as middle-high viscosity petroleum, mineral oil, diester oil, polyester oil, vegetable oil etc.)
Wood coating
Using
When it is used in Grease Lubricant, polar activator is needed. Polar activator is acetone/water(95/5). The dosage of activator is 20%-30% of the weight of CP-250A. And also high shear can promote the dispersing of CP-250A.
Adding procedure as follows:
If condition permits, heat the base oil to 60~70℃
Add CP-250A while stirring, addition level is 7%-10% of the total formulation. Stir 5~10minutes
Add polar activator, addition level is 2%-3% of the total formulation. Then add other additives, stir 25~30m
Use pump to help it pass colloid grinding and homogenizer.
Deair, filtrate, pack.
Note: With High-speed dispersant of grinding machine, and properly prolong the dispersing time, better gelatin performance can be reached.
The Lubricanting grease which uses organoclay as thickener will own high dropping point, thus can be used under high temperature and presents good impermeability and water resistance.
Safety
All safety information is provided in the Material Safety Data Sheets for Zhejiang Camp-Shinning New Material Co.,Ltd..
Package
Kraft paper bag with PE liner or multi-wall paper sacks or customized. 25kg/bag or 22.68kg/bag or customized
Storage
CP-250A has a shelf life of 2 years, and should be stored in ventilated cool and dry place.
Notice
The information on use is based on data which are believed reliable, but any recommendation or suggestion made are without guarantee or warranty, since the conditions of use are outside our control.
All products are sold on the conditions that purchasers shall make their own tests to determine the suitability of such products for their purpose and that all risks are assumed by user. We disclaim any responsibility for damages resulting from careless or improper handling or use. Nothing herein is to be taken as permission, inducement or recommendation to practice any patented invention without a license.
We have several grades of organoclay could use for different base oil in grease.
————————————————————————————————————
We are now looking for Global Distributors, Welcome to cooperate with us !
⇒ You are welcome to send us an email to know the latest information about organoclay.We would like to send you the latest catalogue, or free organoclay
Lubricant Additives ：Application of Organo Bentonite in Lubricants.
We will deeply discuss the application of lubricant additives in lubricating grease and its role as organoclay bentonite in lubricant. We will also consider the positive role of polar activator and organic bentonite clay in lubricant and the whole formula.
Organoclay use for lubricating grease
When we apply rheological additives to lubricating grease, they actively improve the thickening performance of the lubricant and its anti settling performance. Its suspension performance and thixotropy will also give you unexpected gains.
To actively increase the viscosity and lubricity of lubricating grease is the goal of all our grease factories，The rheological parameters can be improved by adding organoclay bentonite into the formula.
We must mention that to meet the rheological properties of the lubricant, it mainly depends on the amount of organic bentonite added, its shear time and shear speed.
The order in which organic bentonite is added to the grease formula is ignored by many grease supply factories, because the change of the order in which it is added will also lead to rheology and greatly affect the performance.
Application of polar activator in grease formulation.
Firstly, polar activator is an important additive in the lubricating oil formula. This component is a high–urity additive, which has been applied to organic bentonite with high gel efficiency, excellent thixotropy and good anti sedimentation performance. The lubricant additive can be used in many different types of grease formulas.
Organoclay use for lubricating grease
Although the influence of polar activator on the overall structure and rheology of lubricating grease is relatively small, it plays a positive role, because organophilic clay bentonite can affect a good fusion between the thickener in the lubricating grease and the base oil.
At the same time, the main influence of the lubricating system is in the initial stage of the production of lubricating grease. Once the production is completed, its influence is very, very small.
In the grease formula, the polar activator affects the rheological properties of the grease by changing the polarity of the base oil. Based on the high polar , the lubricant of the oil only shows a greater density than that based on the low polar . When shearing occurs, the polarity of the base oil is also important for the structural of the grease.
Organoclay use for lubricating grease
It must be noted that the use of polar activator will not affect the viscosity of the lubricating grease, but it will affect the rheological property of the lubricating oil, and can also improve the wear resistance of the lubricant.
If you are using high–emperature lubricating grease, please specially explain to us that we will choose the high–emperature resistant organic bentonite with the model suitable for high–emperature lubricating grease for you.
In order to enhance the adhesion of lubricating grease to the metal surface, the addition of activator in the organic bentonite can improve its additive and its outstanding performance in surface adsorption.
We can clearly see that the polarity of the base oil in the grease will affect the shear stability and consistency of the grease, and the optimal concentration will change with the base oil and additives in the grease.
Therefore, we have to say that polar activators are really crucial for the entire formulation of the lubricant when they are used in organoclay rheological additive.
Organoclay use for lubricating grease
We strongly suggest that before you use our organoclays bentonite in lubricating grease, please contact our sales or our technicians.
We will introduce our products sold in some specific regions to you and give you some guidance, so that you can save a lot of time in the process of testing and exploration. We are also a supplier of organic bentonite as a manufacturer & supplier, We don’t just supply you with goods.
With high–uality product quality, we hope to help you find the most cost–ffective model of organoclays bentonite to apply to your grease formula, so that you can save costs in mass production and maintain long–term product quality stability.
We welcome you to contact us now, and we look forward to hearing from you.
