OBM Organoclay CP-EDS

Rheology modifier

OBM Organoclay CP-EDS

OBM Organoclay CP-EDS is a kind of organo clay rheological additive.  Organoclay Viscosifiers is used in systems of medium polarity and high polarity system. OBM Organoclay Bentonite CP-EDS is suitable for Aromatic solvent system and no-solvent inks, sealant and adhesive.

OBM organoclay
OBM organoclay


Properties | OBM Organoclay

Composition                               Organic derivative of a montmorillonite clay

Appearance                                 Fine powder, light yellow

Moisture content (105,2hr)         ≤3.5%

Loss on ignition (1000)             34%-37%

Bulk density                                  0.35~0.45g/cm3

Fineness (<74μm, %)                     ≥95%

Dispersion fineness (μm)                10


 Advantages |
OBM Organoclay

High efficiency

Fine particle size and easy dispersing

The gel is of light colour and high clarity

Easy to use, it can be added directly in powder

Consistent development of rheology

Can be used to post correct

Application

Solvent Borne OBM Organoclay CP-EDS is used in the following applications:

Lubricating grease

Paints

Inks

Cosmetics

Cleaning agent

Oil drilling mud

Using

Solvent based obm Organoclay CP-EDS When it is used in grease, suitable polar activators are acetone, 95% ethanole, 95% methanol, dipropyl carbonate. Procedures are suggested as below

1.Heat the solvent to 6070

2. Add CP-EDS (7%-10% in weight of total formulation) under agitation.

3. Add polar activator (3% of in weight of total formulation) and other additives, mix at high speed for 25-30 minutes.

4. Pump it to pass through gel grinder or homogenizer.

5. Air driving, filtering, and packing.

In other application, no need to heat the solvent, but pre-gel procedure is necessary.

Commonly addition level is 0.2%-2%.

Safety

All safety information is provided in the Material Safety Data Sheets for Zhejiang Camp-Shinning New Material Co.,Ltd..

Package

Kraft paper bag with PE liner or multi-wall paper sacks or customized. 25kg/bag or 22.68kg/bag or customized

Storage

Rheology OBM organoclay CP-EDS has a shelf life of 2 years, and should be stored in ventilated cool and dry place.

Notice

The information on use is based on data which are believed reliable, but any recommendation or suggestion made are without guarantee or warranty, since the conditions of use are outside our control. OBM Organoclay are sold on the conditions that purchasers shall make their own tests to determine the suitability of such products for their purpose and that all risks are assumed by user. We disclaim any responsibility for damages resulting from careless or improper handling or use. Nothing herein is to be taken as permission, inducement or recommendation to practice any patented invention without a license.

If you are interesting our organoclay,pls mail us.

[email protected]

Rheology organoclay CP-APA

реологическая добавка

Rheology organoclay CP-APA

Rheology organoclay CP-APA is a kind of organo clay rheological additive. Organoclay Bentonite is used in systems containing moderate to highly polar solvents (ketones, ester, ether esters, alcohols, aromatic).

Properties

Composition                      Organic derivative of a montmorillonite clay

Appearance                       Fine powder, off white

Moisture content (105℃,2hr)         ≤3.5%

Loss on ignition (1000℃)            32%-35%

Bulk density                       0.35~0.45g/cm3

Fineness (<74μm, %)               ≥98%

Advantages

High efficiency

Easy to use

No need for polar activator

Can be used to post correct

Application

Organoclay Viscosifiers CP-APA is used in the following applications:

Industrial paint

Sealants & adhesive

Ink

Cosmetic

Nano-composite

Using

Rheology organoclay CP-APA can be added directly in powder. The addition is recommended to be before grinding procedure to get the best effectiveness. Addition level is commonly 0.2%~2.0%.

Safety

All safety information is provided in the Material Safety Data Sheets for Zhejiang Camp-Shinning New Material Co.,Ltd..

Package

Rheology organoclay packed in kraft paper bag with PE liner or multi-wall paper sacks or customized. 25kg/bag or 22.68kg/bag or customized

Storage

Solvent based Organoclay CP-APA has a shelf life of 2 years, and should be stored in ventilated cool and dry place.

Notice

The information on use is based on data which are believed reliable, but any recommendation or suggestion made is without guarantee or warranty, since the conditions of use are outside our control. Organoclay are sold on the conditions that purchasers shall make their own tests to determine the suitability of such products for their purpose and that all risks are assumed by user. We disclaim any responsibility for damages resulting from careless or improper handling or use. Nothing herein is to be taken as permission, inducement or recommendation to practice any patented invention without a license.

Organoclay Bentonite CP-180B

реологическая добавка

Organoclay Bentonite CP-180B

Organoclay Bentonite CP-180B is an organo clay (modified montmorillonite), designed especially for use in solvent based system including intermediate and low polarity polarity range organic liquid. Organoclay is an improved grade of CP-180. Organoclay rheological additive is more fine, and easier to be dispersed compared with Solvent based Organoclay CP-180.

Properties

Composition                               Organic derivative of a montmorillonite clay

 Appearance                                Fine powder, light yellow

Moisture content (105℃,2hr)         ≤3.5%

Loss on ignition (1000℃)             29%-32%

Bulk density                                 0.53g/cm3

Fineness (<74μm, %)                   ≥98%

Advantages

Exerts gelling efficiency over a wide range of intermediate and low polarity

Easy dispersing

The gel is colourless and of high clarity

Produce reproducible thixotropic consistency over a wide temperature range

Imparts particle suspension, sag resistance without impairing flow and leveling, preventing hard settling of pigment and filler

Exerts strong film reinforcing action in organic binder systems

Application

Organoclay Viscosifiers CP-180B is used in the following applications:

Transparent coatings

Lubricant Grease, ink, sealant

Cosmetic

Nano-composite

 Replacement of fumed silica

Using

Organo bentonite CP-180B disperses under high shear and requires a polar activator (30%~40%)  for best efficiency. Heat is not required to obtain good dispersion. Addition levels are typically in 0.2%~2.0%. Polar activator (95% Ethanol or 95% Methanol) is needed. Normally addition level of polar activator is recommended to be 30%~40% of Rheology organoclay CP-180B in weight.

Safety

All safety information is provided in the Material Safety Data Sheets for Zhejiang Camp-Shinning New Material Co.,Ltd..

Package

Kraft paper bag with PE liner or multi-wall paper sacks or customized. 25kg/bag or 22.68kg/bag or customized

Storage

Solvent Borne Organoclay CP-180B has a shelf life of 2 years, and should be stored in ventilated cool and dry place.

Notice

The information on use is based on data which are believed reliable, but any recommendation or suggestion made are without guarantee or warranty, since the conditions of use are outside our control.Rheology organoclay are sold on the conditions that purchasers shall make their own tests to determine the suitability of such products for their purpose and that all risks are assumed by user. We disclaim any responsibility for damages resulting from careless or improper handling or use. Nothing herein is to be taken as permission, inducement or recommendation to practice any patented invention without a license.

If you are interesting our organoclay, pls mail us:

[email protected]

Organo bentonite Viscosifiers

white bentonite clay

Organo bentonite Viscosifiers CP-187A

Organo bentonite Viscosifiers CP-187A is modified bentonite. Organo bentonite Viscosifiers is mainly used in water-borne system.

Properties

Composition                                  Inorganic modified montmorillonite clay

Appearance                                  Free flowing offwhite powder

Moisture content (105℃,2hr)         ≤12%

Bulk density                                   0.55~0.65g/cm3

Fineness (<74μm, %)                   ≥93%

Heavy metal ( Pb)                        ≤15mg/kg

Characteristics and Application

Organo bentonite Viscosifiers CP-187A is Li-bentonite which is made from bentonite by purifying and modifying. Good thixotropic property, high dilatability, good thickening.

Used in water-based coatings and alcoholic group systems, precision casting,

ceramic color oil coatings, emulsion coatings, blunge water, self-leveling flooring

compounds, etc.Water-borne sealant, adhesive

Package and Storage

Kraft paper bag with PE liner or multi-wall paper sacks or customized. 25kg/bag or 22.68kg/bag or customized

Organoclay CP-187A has a shelf life of 2 years, and should be stored in ventilated cool and dry place.

Notice

The information on use is based on data which are believed reliable, but any recommendation or suggestion made is without guarantee or warranty, since the conditions of use are outside our control. Organo bentonite are sold on the conditions that purchasers shall make their own tests to determine the suitability of such products for their purpose and that all risks are assumed by user. We disclaim any responsibility for damages resulting from careless or improper handling or use. Nothing herein is to be taken as permission, inducement or recommendation to practice any patented invention without a license.

If you are interesting our organoclay,pls mail us

[email protected]

Rheology modifier CP-300A

Rheology modifier

Rheology Modifier In Paint

Rheology Modifier

Rheology modifiers in paints could prevent hard settling of pigment and fillers. Rheology modifier CP-300A has good thixotropy in paints coatings.

 Organic bentonite clay is an Organoclay rheological additive (modified montmorillonite), Rheology modifier designed especially for use in solvent based system including intermediate and low polarity range organic liquid.

Rheology modifiers in paints

Rheology modifiers in paints
Rheology modifiers in paints

Properties

Composition                              Organic derivative of a montmorillonite clay

Appearance                                Fine powder, white

Moisture content (105℃,2hr)       ≤3.5%

Loss on ignition (1000℃)            29%-32%

Bulk density                               0.53g/cm3

Fineness (<74μm, %)                  ≥98%

Advantages

  • Exerts gelling efficiency over a wide range of intermediate and low polarity
  • Easy dispersing
  • The gel is colourless and of high clarity
  • Produce reproducible thixotropic consistency over a wide temperature range
  • Imparts particle suspension, sag resistance without impairing flow and leveling, preventing hard settling of pigment and fillers
  • Exerts strong film reinforcing action in organic binder systems

Application

Rheology modifier CP-300A is used in the following applications:

  • Paints & coatings with solvent of low to medium polarity
  • Lubricant Grease, ink, sealant
  • Cosmetic
  • Refractory

Using

Rheology modifier CP-300A disperses under high shear and requires a polar activator (30%~40%)  for best efficiency. Heat is not required to obtain good dispersion.

Addition levels are typically in 0.2%~2.0%. Polar activator (95% Ethanol or 95% Methanol) is needed.

Normally addition level of polar activator is recommended to be 30%~40% of  Rheology modifier CP-300A in weight.

Safety

All safety information is provided in the Material Safety Data Sheets for Zhejiang Camp-Shinning New Material Co.,Ltd..

Package

Kraft paper bag with PE liner or multi-wall paper sacks or customized. 25kg/bag or 22.68kg/bag or customized

Storage

Rheology modifier CP-300A has a shelf life of 2 years, and should be stored in ventilated cool and dry place.

Notice

The information on use is based on data which are believed reliable, but any recommendation or suggestion made are without guarantee or warranty, since the conditions of use are outside our control. All Rheology modifier are sold on the conditions that purchasers shall make their own tests to determine the suitability of such products for their purpose and that all risks are assumed by user. We disclaim any responsibility for damages resulting from careless or improper handling or use. Nothing herein is to be taken as permission, inducement or recommendation to practice any patented invention without a license.

If you are interesting our products,pls mail us:

[email protected]

Mob:  0086- 13185071071

Rheology modifiers in paints

Rheology modifiers in paints

Rheology Modifier For Oil

Rheology Modifier is an additive used in paints and coatings. It is also widely used in sealants, inks, and greases.

It plays a good suspension performance in drilling fluid. Therefore, in many industrial fields, we call them suspension agents, thickeners, convenient rheological basis, and so on.

The choice of rheology modifier for a particular application is important, but not always easy. Different types of products are suitable for different applications, and the selection of a rheology additive is important to ensure that the product you make flows well.

To find the right dilution ratio, you can use a rheology calculator. Then, choose a rheology modifier based on the desired flow rate and determine the amount of rheology modifier to add to the formula.

Rheology modifiers are common additives in many industries and are used to control viscosity and non-Newtonian behaviors.

These substances can be used to improve the shelf-life, texture and processability of formulations.

For example, rheology measurements can help to probe the impact of different formulation changes on the stability and processability of protein solutions. Today, hundreds of different reticulation-based polymers are available to suit your specific needs.

Another type of rheology modifier is organically modified clay.  In order to create a rheology-modifying product, the organically modified clay has to be wetted in a solvent and separated by shear forces.

To add rheology to a formulation, an activator is added to the mixture. This activator can penetrate the layers of the clay, forming loose stacks.

When you choose rheological additives, you choose a solution to improve the performance of the finished product, which can effectively improve the performance of the whole formula, especially in rheological properties.

Rheological additives can promote better long-term storage and transportation, and make effective adjustments according to the formula, so that it can greatly improve its rheological properties and rheological properties.

This material also provides improved leveling and durability. It is more convenient to handle and can make the final product more resistant to drips.

However, rheology-modifiers are still a popular choice for active ingredients and are available for virtually any application.

The main benefits of a rheology-modifier include the ease of use, the ability to increase the stability and suspensibility of a product, and its compatibility with other ingredients. Besides its benefits, rheology-modifiers have many advantages.

They are highly effective for a variety of applications. Its primary advantage is its ease of use. Moreover, it can be easily incorporated into any formulation without causing pre-swelling.

There are a wide range of rheology-modifiers available for various applications. The most common benefits of rheology-modifiers are its high compatibility and high suspensibility. Unlike xanthan gum, a rheology-modifier is compatible with almost any kind of formulation.

As a result, it is often used instead of xanthan gum. This is because a rheology-modifier can be added to a liquid without affecting the performance of the product.

Despite its high price, rheology-modifiers are an important ingredient for nearly every industry. Compared to xanthan gum, rheo-modifiers are better at preventing the settling of inorganic particles in a liquid.

These products are highly durable and can be used in the field as they are used by a wide variety of people. They also have superior anti-sag and anti-settling properties.

Rheology-modifiers are organically-modified clays that are colloidal in nature. They are a form of polymer chains and micelles that are formed when the hydrophilic portions of the molecules are separated from the hydrophilic ones.

They have excellent anti-sag and anti-settling properties. They are also a good replacement for hydroxyethyl cellulose, which is commonly used in cosmetics and personal care products.

Rheology-modifiers are used to provide wetting properties in products. They are a good substitute for hydroxyethyl cellulose. These additives can provide better wetting and anti-sag properties.

They can replace hydroxyethyl cellulose, which is a natural polymer that forms micelles in water. For these reasons, rheology-modifiers can be a valuable addition to formulations.

There are several types of rheology-modifiers. Typically, they are classified into two groups – inorganic chemistries and organic-based systems.

There are a variety of uses for rheology-modifiers, and their use is highly dependent on the product’s intended use. There are several benefits of adding rheology-modifiers to your product, but there are also some drawbacks.





Email: [email protected]           Wechat/Whatsapp: +86-13185071071

CP-982 Organophilic clay

OBM grade organophilic Clay

Organophilic clay CP-982 is a moderate temperature performance amine-treated Bentonite. Organophilic clay is a cost-effective product, particularly in all-oil, invert diesel and mineral oil based fluids, where sufficient shear is available to achieve full dispersion.Organophilic clay CP-982 viscosifier is used to increase carrying capacity and suspension properties, providing support for weight materials and improved cutting removal.

Properties

Composition                                        Organically modified bentonite clay

Appearance                                        Off white to tan free-flowing powder

Moisture content (105℃,2hr)               ≤4%

Particle size (150 mesh)                      ≥98%

Specific Gravity                                   1.7

Bulk Density, kg/m3                                  500

30% Diesel Oil Gel, 600rpm, CP           ≥30

30% Diesel Oil Gel, Yield Point            About 8

Advantages

  • Effective viscosifier and gellant
  • Aids control of fluid loss to the formation
  • Increases emulsion stability
  • Improves cuttings carrying and hole cleaning capacity
  • Suspends weighting materials and other solids
  • Confers temperature stability to the fluid

Application

Base oil:

  • Diesel Oils
  • CrudeOils
  • Mineral Oils
  • Synthetic Oil

Viscosifying drilling Fluids:

  • Oil based drilling fluids
  • Invert emulsion fluids
  • Workover fluids
  • Completion fluids
  • Casing packs
  • Packer fluids
  • Spotting fluids

Safety

All safety information is provided in the Material Safety Data Sheets for Zhejiang Camp-Shinning New Material Co., Ltd.

Package

Organophilic clay packed in kraft paper bag with PE liner or multi-wall paper sacks or customized. 25kg/bag or 50LB/Sack or customized

Storage

Organophilic clay CP-982 Store in a dry, well-ventilated area with temperature of 0℃-30℃.  Keep container closed. The quality guarantee period is 24 months.

Notice

The information on use is based on data which are believed reliable, but any recommendation or suggestion made is without guarantee or warranty, since the conditions of use are outside our control. Organophilic clay are sold on the conditions that purchasers shall make their own tests to determine the suitability of such products for their purpose and that all risks are assumed by user. We disclaim any responsibility for damages resulting from careless or improper handling or use. Nothing herein is to be taken as permission, inducement or recommendation to practice any patented invention without a license.



If you are interesting our CP-982 Organophilic clay,PLs mail us:

 [email protected]



Cel:   0086-131 85 071 071
