Organophilic Clay Bentonite Powder For Packer Fluids Completion Fluids Workover Fluids

Organoclay For Grease

Organophilic clay for Packer fluids Completion fluids Workover fluids

Organophilic clay viscosifier as a drilling fluids chemicals in all–oil systems or in other fluids where no water is included in the formulation, or where water is unwanted, a chemical activator such as methanol or propylene carbonate should be added. Mixing 5% water, by weight, into the activator can enhance its efficiency.

CP-992 is an easy dispersing, self activating organoclay bentonite that exhibits high performance efficiency in diesel, low aromatic mineral oil, modified vegetable oil and synthetic base fluid formulation.Organophilic Clay CP-992  is a wet process improved viscosifier and gelling agent. It is an easy dispersing, rapid yielding organoclay. It is stable and has good suspension and thixotropic features.

1, Properties

Composition Organically modified bentonite clay

Appearance Off white to tan finely divided powder,

Moisture content (105℃,2hr) ≤3.5%

Particle size (<76μm or 200mesh) ≥98%

Specific Gravity 1.7

2, Organophilic clay viscosifier  Advantages

  • Disperses easily in less time with less shear
  • High performance viscosifier for low aromatic, all mineral oil and synthetic base fluids
  • Cost- effectively builds viscosity and yield point
  • Aids control of fluid loss to the formation
  • Increases emulsion stability
  • Suspends weighting materials and other solids
  • Confers stability at the pressure and temperature 108Pa and 230℃

3, Application

   Base oil:

  • Diesel Oils
  • Crude Oils
  • Mineral Oils
  • Synthetic Oil
  • Alpha Olefins
  •       Low BTEX base oil

Viscosifying drilling Fluids:

  • Oil based drilling fluids
  • Invert emulsion fluids
  • Workover fluidsl
  • Completion fluids
  • Casing packs
  • Packer fluids
  • Spotting fluids

4, Safety

All safety information is provided in the Material Safety Data Sheets for Zhejiang Camp-Shinning New Material Co., Ltd.

5, Package

Kraft paper bag with PE liner or multi-wall paper sacks or customized. 25kg/bag or 22.68kg/bag or customized

6, Storage

CP-992 Store in a dry, well-ventilated area with temperature of 0℃-30℃. Keep container closed. The quality guarantee period is 24 months.

7, Notice

The information on use is based on data which are believed reliable, but any recommendation or suggestion made is without guarantee or warranty, since the conditions of use are outside our control. All products are sold on the conditions that purchasers shall make their own tests to determine the suitability of such products for their purpose and that all risks are assumed by user. We disclaim any responsibility for damages resulting from careless or improper handling or use. Nothing herein is to be taken as permission, inducement or recommendation to practice any patented invention without a license.

Ask A Quote
Posted on

Easy Dispersing Rheological Additive With Good Self Activating In Fracture Fluids , All Oil

Organoclay manufacturer in China

Easy dispersing Rheological Additive with good self activating in fracture fluids , All oil

Rheological additive CP-180B is a organo bentonite. Organophilic clay is special in mineral oil base drilling fluid diesel based, white oil based。Organic bentonite , Modified bentonite can change oil base drilling fluid rheology, suspension of carrying  and in drilling fluid can improves cuttings carrying capacity and hole cleaning . Increases emulsion stability. Organic clay greatly improve the drilling fluid yield stress also improve the drilling fluid at low shear viscosity under shear, protecting borehole wall.

1, Properties

Composition                               Organic derivative of a montmorillonite clay

Appearance                                Fine powder, light yellow

Moisture content (105℃,2hr)     ≤3.5%

Loss on ignition (1000℃)          29%-32%

Bulk density 0.53g/cm3

Fineness (<74μm, %)                 ≥98%

2, Advantages

  • Exerts gelling efficiency over a wide range of intermediate and low polarity
  • Easy dispersing
  • The gel is colourless and of high clarity
  • Produce reproducible thixotropic consistency over a wide temperature range
  • Imparts particle suspension, sag resistance without impairing flow and leveling, preventing hard settling of pigment and filler
  • Exerts strong film reinforcing action in organic binder systems

3, Application

    CP-180B is used in the following applications:

  • Viscosifying drilling fluids including:
  •  Invert emulsion muds
  •  Packer fluids
  •  Workover fluids
  •  OIl drilling mud
  • Based on:
    Diesel oil
    Crude oil
    Mineral oil
Chemical ingredientAlkyl Quaternary Ammonium bentoniteQuartz(SiO2)
CAS. No.68953-58-214808-60-7
Content>99%<1%
ItemStandardResult
AppearanceFine powder, light whiteFine powder, light white
Moisture Content(105℃, 2hr)≤3.5%2.5%
Viscosity, mpa(20-25℃)≥9004800
Fineness(<0.074mm)≥98%99.8%

4, Using

CP-180B disperses under high shear and requires a polar activator (30%~40%) for best efficiency. Heat is not required to obtain good dispersion. Addition levels are typically in 0.2%~2.0%. Polar activator (95% Ethanol or 95% Methanol) is needed. Normally addition level of polar activator is recommended to be 30%~40% of CP-180B in weight.

5, Safety

All safety information is provided in the Material Safety Data Sheets for Zhejiang Camp-Shinning New Material Co.,Ltd..

6, Package

Kraft paper bag with PE liner or multi-wall paper sacks or customized. 25kg/bag or 22.68kg/bag or customized

7, Storage

CP-180B has a shelf life of 2 years, and should be stored in ventilated cool and dry place.

8, Notice

The information on use is based on data which are believed reliable, but any recommendation or suggestion made are without guarantee or warranty, since the conditions of use are outside our control. All products are sold on the conditions that purchasers shall make their own tests to determine the suitability of such products for their purpose and that all risks are assumed by user. We disclaim any responsibility for damages resulting from careless or improper handling or use. Nothing herein is to be taken as permission, inducement or recommendation to practice any patented invention without a license.

Ask A Quote
Posted on

Thickening Agent Organoclay Rheological Additive Used Grease Lubricant

Rheology modifiers

Thickening agent Organoclay Rheological Additive used Grease lubricant with anti corrosion

Organoclay Rheological Additive | Oil thickening additive CP-250A is a kind of purified and modified organoclay , designed especially for using in Grease based on synthetic oils such as vegetable oil, polyester oil.

Modified organic bentonite has high gelling efficiency, fine thixotropy and perfect anti-settling.Rheology modifier as naphthenic oils, paraffinic mineral oil and synthetic oil thickening agent  has corrosion resistance high temperature performance and good thickening property, bentonite grease, can also be  as a solid lubricant in the oil carrier thickener, suspending agent.

oil thickening additive
oil thickening additive

1, Properties

Composition Organic derivative of a montmorillonite clay

Appearance                                               Fine powder, light yellow

Moisture content (105℃,2hr)                     ≤3.5%

Loss on ignition (1000℃)                           34%-36%

Bulk density                                                0.42g/cm3

Fineness (<74μm, %)                                 ≥98%

Commodity

Rheological additive

Chemical ingredientAlkyl Quaternary Ammonium bentoniteQuartz(SiO2)
CAS. No.68953-58-214808-60-7
oil thickening additive
oil thickening additive

2, Advantages

  • High efficiency
  • The gel is of light colour and high clarity
  • Easy to use, no need to pregel
  • Eliminate polar activator
  • Consistent development of rheology
  • Can be used to post correct

3,  Application

Oil thickening additive CP-250A is used in the following applications:

  • Grease Lubricant (the base oil is synthetic oil such as middle-high viscosity petroleum, mineral oil, diester oil, polyester oil, vegetable oil etc.)
  • Wood coating

4,  Using

When it is used in Grease Lubricant, polar activator is needed. Polar activator is acetone/water(95/5). The dosage of activator is 20%-30% of the weight of CP-250A. And also high shear can promote the dispersing of CP-250A.

Adding procedure as follows:

  • If condition permits, heat the base oil to 60~70℃
  • Add CP-250A while stirring, addition level is 7%-10% of the total formulation. Stir 5~10minutes
  • Add polar activator, addition level is 2%-3% of the total formulation. Then add other additives, stir 25~30minutes.
  • Use pump to help it pass colloid grinding and homogenizer.
  • Deair, filtrate, pack.

5, Note:

With High-speed dispersant of grinding machine, and properly prolong the dispersing time, better gelatin performance can be reached.

The Lubricanting grease which uses organoclay as thickener will own high dropping point, thus can be used under high temperature and presents good impermeability and water resistance.

6, Safety

All safety information is provided in the Material Safety Data Sheets for Zhejiang Camp-Shinning New Material Co.,Ltd..

7, Package

Outside the package of kraft paper bag, the inner packing uses the double layer packing of the polyethylene film bag, or the paper bag packing, the weight is usually 25 + 0.25kg,  or 22.68kg/bag or customized

8, Storage

Thickening agent Rheological Additive CP-250A has a shelf life of 2 years, and should be stored in ventilated cool and dry place.

9, Notice

The information on use is based on data which are believed reliable, but any recommendation or suggestion made are without guarantee or warranty, since the conditions of use are outside our control.

All oil thickening additive are sold on the conditions that purchasers shall make their own tests to determine the suitability of such products for their purpose and that all risks are assumed by user.

We disclaim any responsibility for damages resulting from careless or improper handling or use. Nothing herein is to be taken as permission, inducement or recommendation to practice any patented invention without a license.

Sales Dept:   [email protected]

Cell ( Whatsapp):    +86-13185071071


oil thickening additive
Ask A Quote
Posted on

Montmorillonite clay organoclay for UV ink , Offset Inks , Screen printing ink

Montmorillonite clay organoclay

Montmorillonite Clay Organoclay

Ask A Quote
Montmorillonite clay organoclay
Posted on

Organo bentonite increase yield point and gel strength , improve the carrying capacity

Organofilic clay

Organo bentonite increase yield point and gel strength , improve the carrying capacity

Organo bentonite is a highly effective, gel – forming organophilic clay composed of amontmorillonite clay reacted with

a high purity organic compound.  Rheological additive is used to economically increase viscosity in oil – base mud systems.

1, Properties

COMPOSITIONOrganic derivative of a bentonite clay
Moisture content (105℃,2hr) %≤3.50
FINENESS (<74μm, %)≥98.0
Bulk density,kg/m3≤400
AppearanceFine powder, white

2, Advantages

  • Easy dispersing
  • Improves mud plant throughput
  • Requires no external chemical activators in all-oil or invert systems
  • The gel is colourless and of high clarity
  • Produce reproducible thixotropic consistency over a wide temperature range
  • Imparts particle suspension, sag resistance without impairing flow and leveling

3, Application

CP-169 is used in the following applications:



  • Oil drilling mud
  • Diesel Oils



  • Mineral Oils



  • Synthetic Oil
  • Linear and isomerized Alpha Olefins
  • Modified vegetable oil



4, Using

Organoclay CP-169 disperses under high shear and requires a polar activator (30%~40%) for best efficiency. Heat is not required to obtain good dispersion. Addition levels are typically in 0.2%~2.0%. Polar activator (95% Ethanol or 95% Methanol) is needed. Normally addition level of polar activator is recommended to be 30%~40% of CP-169 in weight.

Commodity



RHEOLOGICAL ADDITIVE



Chemical ingredientAlkyl Quaternary Ammonium bentonite

Quartz(SiO2)





CAS. No.68953-58-2



14808-60-7



5, Safety

All safety information is provided in the Material Safety Data Sheets for Zhejiang Camp-Shinning New Material Co.,Ltd..

6, Package

The package: kraft complex bag interior with PE or customized
The weight: 25±0.25kg per bag or 22.68kg per Bag
The package and weight can be customized
Storage life: two years when the temperature is 0-30℃

7, Storage

Organophilic clay CP-169 has a shelf life of 2 years, and should be stored in ventilated cool and dry place.

8, Notice

The information on use is based on data which are believed reliable, but any recommendation or suggestion made are without guarantee or warranty, since the conditions of use are outside our control. All products are sold on the conditions that purchasers shall make their own tests to determine the suitability of such products for their purpose and that all risks are assumed by user. We disclaim any responsibility for damages resulting from careless or improper handling or use. Nothing herein is to be taken as permission, inducement or recommendation to practice any patented invention without a license.

Ask A Quote
Posted on

Suspends weighting materials Rheology Modifier organoclay increases emulsion stability

Two Methods for Selecting Organoclay Bentonite

Suspends weighting materials Rheology Modifier organoclay increases emulsion stability

Rheology Modifier organoclay CP-138Y is an treated oil based bentonite clay. Rheological additive is an economical organobentonite viscosifier and suspending agent for oil–based muds, invert emulsion muds,completion fluids and workover fluids. Organophilic clay is suitable for drilling fluids based on diesel oil , Synthetic oil and mineral oil. Modified bentonite adds to the formulation the temperature stable rheology characteristic of organoclay .

1, Advantages

  • Improves cuttings carrying capacity and hole cleaning
  • Increases emulsion stability
  • Aids control of fluid loss to the formation
  • Cost-effectively builds viscosity and yield point
  • Suspends weighting materials and other solids

2, Typical properties

CompositionOrganic derivative of a montmorillonite clay
AppearanceFine powder, light yellow
Moisture content (105℃,2hr)≤3.5%
Loss on ignition max,%(1000℃)(32.5±1.5)%
Bulk density0.40~0.60g/cm3
Fineness (<74μm, %)≥99%
Dispersion fineness (μm)≤10

3, Application

Base oil:

  • Diesel Oils
  • Mineral Oils
  • Synthetic Oil
  • Linear and isomerized Alpha Olefins
  • Modified vegetable oil

Viscosifying drilling Fluids:

  • All oil based drilling fluids
  • Invert emulsion fluids
  • Workover fluids
  • Fracture fluids

4, Using

It can be added directly in powder under high shear condition. Addition level is commonly 0.1%~1.0% of total formulation by weight. Polar activator is required to achieve better performance. The addition procedure is suggested as below.

  • Add resin in solvent.
  • Add CP-138Y under slow agitation.
  • Disperse under high speed for 10-15 minutes.
  • Add polar activator.
  • Disperse under high speed for 10-15 minutes.
  • Add wetting agent and other additive.
  • Grinding and next procedure.

If to make pre-gel, better efficiency can be achieved. Addition level in pre-gel is 5%-8% of total pre-gel in weight. Pre-gel procedure is as below.

  • Add solvent or solvent mixture.
  • Add CP-138Y under slow agitation.
  • Disperse under high speed for 5-10 minutes.
  • Add polar activator.
  • Disperse under high speed for 5-10 minutes.

Polar activator is suggested to be ethanol/water (95/5), methanol/water (95/5) or acetone. Dosage of polar activator is as below.

5, Safety

All safety information is provided in the Material Safety Data Sheets for Zhejiang Camp-Shinning New Material Co., Ltd.

6, Package

Kraft paper bag with PE liner or multi-wall paper sacks or customized. 25kg/bag or 50LB/Sack or customized

7, Storage

CP-982S Store in a dry, well-ventilated area with temperature of 0℃-30℃. Keep container closed. The quality guarantee period is 24 months.

8, Notice

The information on use is based on data which are believed reliable, but any recommendation or suggestion made is without guarantee or warranty, since the conditions of use are outside our control. All products are sold on the conditions that purchasers shall make their own tests to determine the suitability of such products for their purpose and that all risks are assumed by user. We disclaim any responsibility for damages resulting from careless or improper handling or use. Nothing herein is to be taken as permission, inducement or recommendation to practice any patented invention without a license.
